Welcome
Congratulations on your purchase of a new
Honda vehicle. Your selection of a Honda
makes you part of a worldwide family of
satisfied customers who appreciate Honda's
reputation for building quality into every
product.
To ensure your safety and riding pleasure:
●Read this owner's manual carefully.
●Follow all recommendations and
procedures contained in this manual.
●Pay close attention to safety messages
contained in this manual and on the
vehicle.
To protect your investment, we urge you to
take responsibility for keeping your vehicle
well serviced and maintained. Also, observe
the break-in guidelines, and always perform
the pre-ride inspection and other periodic
checks in this manual.
When service is required, remember that
your Honda dealer knows your vehicle best.
If you have the required mechanical “know-
how” and tools, you can purchase an official
Honda Service Manual to help you perform
many maintenance and repair tasks. P. 1222
Read the warranty information thoroughly so
that you understand the warranty coverage
and that you are aware of your rights and
responsibilities. P. 1232
You may also want to visit our website at
www.powersports.honda.com.
Happy riding!
A Few Words About Safety
Your safety, and the safety of others, is very
important. Operating this vehicle safely is an
important responsibility.
To help you make informed decisions about
safety, we have provided operating
procedures and other information on safety
labels and in this manual. This information
alerts you to potential hazards that could
hurt you or others.
Of course, it is not practical or possible to
warn you about all hazards associated with
operating or maintaining a vehicle. You must
use your own good judgment.
You will find important safety information in a
variety of forms, including:
●Safety labels on the vehicle
●
Safety Messages preceded by a safety alert
symbol and one of three signal words:
DANGER, WARNING, or CAUTION.
These signal words mean:
3DANGER
You WILL be KILLED or SERIOUSLY
HURT if you don’t follow instructions.
3WARNING
You CAN be KILLED or SERIOUSLY
HURT if you don’t follow instructions.
3CAUTION
You CAN be HURT if you don’t follow
instructions.
Other important information is
provided under the following titles:
NOTICE Information to help you avoid
damage to your vehicle, other
property, or the environment.
Safety Guidelines.................................................P. 3
Safety Labels.........................................................P. 7
Safety Precautions............................................... P. 9
Riding Precautions............................................ P. 10
Accessories & Modifications........................... P. 14
Loading ................................................................P. 15
This section contains important information for safe riding of your vehicle.
Please read this section carefully.
Vehicle Safety
Safety Guidelines
Follow these guidelines to enhance your safety:
●Perform all routine and regular inspections
specified in this manual.
●Stop the engine and keep sparks and flame
away before filling the fuel tank.
●Do not run the engine in enclosed or partly
enclosed areas. Carbon monoxide in
exhaust gases is toxic and can kill you.
Always Wear a Helmet
It's a proven fact: helmets and protective
apparel significantly reduce the number and
severity of head and other injuries. So always
wear an approved helmet and protective
apparel. P. 92
Before Riding
Make sure that you are physically fit, mentally
focused and free of alcohol and drugs. Check
that you and your passenger are both wearing
an approved helmet and protective apparel.
Instruct your passenger on holding onto the
grab rail or your waist, leaning with you in turns,
and keeping their feet on the footpegs, even
when the vehicle is stopped.
Take Time to Learn & Practice
Even if you have ridden other vehicles, practice
riding in a safe area to become familiar with
how this vehicle works and handles, and to
become accustomed to the vehicle's size and
weight.
Safety Guidelines
Vehicle Safety
3
Continued
We recommend that all riders take a certified
course approved by the Motorcycle Safety
Foundation (MSF). New riders should start with
the basic course, and even experienced riders
will find the advanced course beneficial.
For information about the MSF training course
nearest you, call the national toll-free number:
(800) 446-9227.
Other riding tips can be found in the You and
Your Motorcycle Riding Tips booklet that came
with your vehicle.
Ride Defensively
Always pay attention to other vehicles around
you, and do not assume that other drivers see
you. Be prepared to stop quickly or perform an
evasive maneuver.
Make Yourself Easy to See
Make yourself more visible, especially at night,
by wearing bright reflective clothing, positioning
yourself so other drivers can see you, signaling
before turning or changing lanes, and using
your horn when necessary.
Ride within Your Limits
Never ride beyond your personal abilities or
faster than conditions warrant. Fatigue and
inattention can impair your ability to use good
judgment and ride safely.
Don't Drink and Ride
Alcohol and riding don't mix. Even one alcoholic
drink can reduce your ability to respond to
changing conditions, and your reaction time
gets worse with every additional drink. Don't
drink and ride, and don't let your friends drink
and ride either.
Safety Guidelines
Vehicle Safety
4
Safety Labels
Safety and information labels on your vehicle
provide important safety information and may
warn you of potential hazards that could cause
serious injury. Read these labels carefully and
don't remove them.
If a label comes off or becomes hard to read,
contact your dealer for a replacement.
Safety Labels
Vehicle Safety
7
Continued
PCX150A
Safety Precautions
●Ride cautiously and keep your hands on the
handlebar and feet on the floor.
●Keep passenger's hands onto the grab rail
or your waist, passenger's feet on the
footpegs while riding.
●Always consider the safety of your
passenger, as well as other drivers and
riders.
Protective Apparel
Make sure that you and any passenger are
wearing an approved helmet, eye protection,
and high-visibility protective clothing. Ride
defensively in response to weather and road
conditions.
#
Helmet
Should be safety-standard certified, high-
visibility, and correct size for your head
●Must fit comfortably but securely, with the
chin strap fastened.
●Face shield with unobstructed field of vision
or other approved eye protection
Look for a DOT (Department of Transportation)
certification label on any helmet you buy.
3WARNING
Not wearing a helmet increases the
chance of serious injury or death in a
crash.
Make sure that you and any passenger
always wear an approved helmet and
protective apparel.
#
Gloves
Full-finger leather gloves with high abrasion
resistance
Safety Precautions
Vehicle Safety
9
Continued
#
Boots or Riding Shoes
Sturdy boots with non-slip soles and ankle
protection
#
Jacket and Pants
Protective, highly visible, long-sleeved jacket
and durable long pants for riding (or a
protective suit)
Riding Precautions
Break-in Period
During the first 300 miles (500 km) of running,
follow these guidelines to ensure your vehicle's
future reliability and performance.
●Avoid full-throttle starts and rapid
acceleration.
●Avoid hard braking.
●Ride conservatively.
Brakes
Observe the following guidelines:
●
Avoid excessively hard braking.
uSudden braking can reduce the vehicle's
stability.
u
Where possible, reduce speed before
turning; otherwise you risk sliding out.
●
Exercise caution on low traction surfaces.
u
The tires slip more easily on such surfaces
and braking distances are longer.
Riding Precautions
Vehicle Safety
10
3.
Turn the handlebar fully to the left.
uTurning the handlebar to the right
reduces stability and may cause the
vehicle to fall.
4.
Turn the ignition switch to the (Lock)
position ( P. 32), remove the key and close2
the shutter ( P. 33).2
Refueling and Fuel Guidelines
Follow these guidelines to protect the engine,
fuel system and catalytic converter:
●Use only unleaded gasoline.
●Use recommended octane number. Using
lower octane gasoline will result in
decreased engine performance.
●Do not use fuels containing a high
concentration of alcohol. P. 1212
●Do not use stale or contaminated gasoline
or an oil/gasoline mixture.
●Avoid getting dirt or water in the fuel tank.
Riding Precautions
Vehicle Safety
13
Left handle grip
Grab rail
Center stand
Accessories &
Modifications
We strongly advise that you do not add any
accessories that were not specifically designed
or approved for your vehicle by Honda or make
modifications to your vehicle from its original
design. Doing so can make it unsafe.
Modifying your vehicle may also void your
warranty and make your vehicle illegal to
operate on public roads. Before deciding to
install accessories on your vehicle be certain the
modification is safe and legal.
3WARNING
Improper accessories or modifications
can cause a crash in which you can be
seriously hurt or killed.
Follow all instructions in this owner's
manual regarding accessories and
modifications.
Do not pull a trailer with, or attach a sidecar to,
your vehicle. Your vehicle was not designed for
these attachments, and their use can seriously
impair your vehicle's handling.
Accessories & Modifications
Vehicle Safety
14
Parts Location
Operation Guide
16
Throttle grip (P. 89)
Document bag (P.46)
Front brake fluid reservoir (P. 82)
Tool kit (P. 46)
Front brake lever
Engine oil fill cap/dipstick (P. 74)
Engine oil drain bolt (P.75)
Fuse box (P.102)
Center compartment (P.46)
Battery (P. 69)
Coolant reserve tank (P. 80)
Battery cover (P. 70)
Brake lock knob
PCX150
(P. 35)
Operation Guide
17
Side stand (P. 88)
Crankcase breather (P.90)
Front box (P. 47)
Accessory socket (P.43)
Rear brake lever (P.84)
Fuel fill cap (P. 41)
Helmet holder (P. 45)
Center stand (P. 12)
Seat (P.44)
Spark plug (P. 71)
Oil plug (P. 75)
Rear bake lock lever
PCX150A
(P. 34)
CBS brake fluid reservoir
PCX150
(P.82)
Air cleaner (P. 78)
Operation Guide
21
Continued
OIL CHANGE indicator
The indicator is turned on whenever the
running distance reaches the programmed oil
change interval.
When the running distance reaches about
600 miles (1,000 km):
Reset the indicator for the 1st time.
When the running distance reaches about
every 4,000 miles (6,000 km) after the 1st time
resetting:
Reset the indicator whenever it is turned on.
After changing the engine oil ((P.75)) , be
sure to reset the indicator.
To reset the indicator, press and hold the
SET
switch while turning the ignition switch to
the ON position, and keep holding the
SET
switch for more than 3 seconds.
The indicator does not go off until it is reset.
If the oil is changed before the oil change indicator comes on, be sure to reset the oil
change indicator after changing the oil.
When resetting the indicator during no indication, the indicator will appear for 2 seconds,
then disappear.
Switches
Operation Guide
30
Headlight dimmer switch
• : High beam
• : Low beam
Start button
Turn signal switch
uPressing the switch turns the
turn signal off.
Horn button
Engine stop switch
Should normally remain in the
(Run) position.
uIn an emergency, switch to the
(Stop) position (the starter
motor will not operate) to stop
the engine.
Specyfikacje produktu
| Marka: | Honda |
| Kategoria: | Silnik |
| Model: | PCX150A (2020) |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z Honda PCX150A (2020), zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje Silnik Honda
16 Lutego 2025
8 Lutego 2025
8 Lutego 2025
2 Lutego 2025
11 Stycznia 2025
8 Stycznia 2025
8 Stycznia 2025
2 Stycznia 2025
31 Grudnia 2025
31 Grudnia 2025
Instrukcje Silnik
- Silnik Yamaha
- Silnik Triumph
- Silnik Kawasaki
- Silnik Milwaukee
- Silnik KTM
- Silnik Ducati
- Silnik BMW
- Silnik GasGas
- Silnik Suzuki
- Silnik Husqvarna
- Silnik Aprilia
- Silnik Mercedes-Benz
- Silnik Danfoss
- Silnik Texas
- Silnik ELAC
- Silnik Kettler
- Silnik Mitsubishi
- Silnik Indian
- Silnik Piaggio
- Silnik Reebok
- Silnik Juki
- Silnik Beta
- Silnik Bajaj
- Silnik Royal Enfield
- Silnik Sherco
- Silnik Hyosung
- Silnik Benelli
- Silnik Cagiva
- Silnik Metabo
- Silnik Nautilus
- Silnik Mash
- Silnik Hero
- Silnik Victory
- Silnik Emco
- Silnik Chang Jiang
- Silnik Harley Davidson
- Silnik Moto Guzzi
- Silnik Derbi
- Silnik SMC
- Silnik Ridley
- Silnik Anova
- Silnik Zero
- Silnik MV Agusta
- Silnik BodyCraft
- Silnik Mahindra
- Silnik CRRCpro
Najnowsze instrukcje dla Silnik
1 Marca 2025
21 Lutego 2025
17 Lutego 2025
14 Lutego 2025
2 Lutego 2025
15 Stycznia 2025
12 Stycznia 2025
10 Stycznia 2025
3 Stycznia 2025
3 Stycznia 2025
