PowerPlant PowerBank+

Read and follow the safety instructions and all other instructions. Keep the manual

for future reference. If you pass the product to another person, please pass the user

manual with it.

Technical specications

 Charging time: 6 hours

 Battery capacity: 96.2 Wh (7.4 V / 13,000 mAh)

 Charging current: 12 V DC / 2000 mA

 Polarity: centre negative / outer barrel positive

 Supply voltage (AC adapter): 100 – 240 V ~, 50/60 Hz

 Output voltage:

1 × 9 / 12 / 18 / 24 V @ max. 2000 mA

2 × 5 V @ max. 2400 mA (USB)

 Dimensions (W × H × D): 138 mm × 105 mm × 39 mm

 Weight: 660 g

Features

 Chargeable power supply

 Automatic overload and short circuit protection

 High end battery adapter with high capacity for eect pedals

 Charging during playing

 Usable for the most multiple power supplies available on the market, as

Harley Benton, Strymon, MXR, Palmer, VoodooLab, CIOKS, etc.

 USB ports for charging smartphones and tablets

 Charging of up to 8 eect pedals simultaneously with the daisy chain

cable

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • info@thomann.de DocID: 473801 / 03.03.2020

For the packaging, environmentally friendly materials have been chosen that can

be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are pro-

perly disposed of. Do not just dispose of these materials with your normal house-

hold waste, but make sure that they are collected for recycling. Please follow the

notes and markings on the packaging.

Batteries do contain some hazardous chemicals so they should not be thrown away

with the normal household waste. They should be returned to the manufacturer for

disposal or recycled elsewhere in accordance with your local regulations. Remove

lithium batteries from the device before disposal. Protect used lithium batteries

against potential short circuits, e.g. by covering the poles with adhesive tape. Dis-

pose the built-in lithium batteries together with the device. Please check for an

appropriate reception facility.

This product is subject to the European Waste Electrical and Electronic Equipment

Directive (WEEE) in its currently valid version. Do not dispose with your normal

household waste. Dispose of this device through an approved waste disposal rm

or through your local waste facility. When discarding the device, comply with the

rules and regulations that apply in your country. If in doubt, consult your local was-

te disposal facility.

Safety instructions

Intended use

This device is designed to charge batteries of eect pedals and other devices. Any other

use or use under other operating conditions is considered to be improper and may re-

sult in personal injury or property damage. No liability will be assumed for damages

resulting from improper use.

External power supply

The device is powered by an AC adaptor plug. Before connecting the AC adaptor plug,

ensure that the input voltage (AC outlet) matches the voltage rating of the device and

that the AC outlet is protected by a residual current circuit breaker. Failure to do so could

result in damage to the device and possibly the user.

Unplug the AC adaptor plug before electrical storms occur and when the device is

unused for long periods of time to reduce the risk of electric shock or re.

Danger for children

Ensure that plastic bags, packaging, etc. are properly disposed of and are not

in the reach of babies and young children. Choking hazard! Ensure that chil-

dren do not touch the powerbank. They could swallow small parts and cho-

ke! Never let children play unattended with the electrical devices.

Incorrect handling of lithium batteries can result in injury

In the event of a short circuit, overheating or mechanical damage, lithium

batteries can cause severe injuries.

Connections and operating elements

ö Blue LEDs; indicate which output voltage has been chosen

# Button to choose the output voltage

$ Button to turn on and o the device by pressing it for 3 seconds

% Green LEDs; indicate the charging status of the battery;

blink during charging the battery

& Connection for the power adapter

' USB ports

( DC output plug for connecting the devices to be charged

(

Scope of delivery

 1 × power adapter (12 V DC, 2000 mA)

 1 × DC cable connector 4.0 × 1.7 mm to connector 5.5 × 2.1 mm

 1 × DC cable connector 4.0 × 1.7 mm to plug 5.5 × 2.1 mm

 1 × EIAJ-05 converter (connector 4.0 × 1.7 mm to connector EIAJ-05)

to Power Strymon power supplies

 1 × daisy chain cable 1-8

Specyfikacje produktu

Marka:	Harley Benton
Kategoria:	Niesklasyfikowane
Model:	PowerPlant PowerBank+
