Strona 1/32

For more product details, please visit GIGABYTE's website.

https://ww w.gigabyte.com/Motherboard/H610M-H-rev-10?m=ma#kf

https://ww w.gigabyte.com/Motherboard/H610M-H-V2-DDR4-rev-10?m=ma#kf

GIGABYTE will reduce paper use in order to fulll the responsibilities of a global citizen.

Also, to reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

H610M H

H610M H V2 DDR4

User's Manual

Rev. 1002

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without

prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

For detailed product information, carefully read the User's Manual.

For quick set-up of the product, refer to the Quick Installation Guide on GIGABYTE's

website.

https://download.gigabyte.com/FileList/Manual/mb_manual_quick-guide_am5.pdf?m=sw

For product-related information, check on our website at: https://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before

updating motherboard BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

Chapter 1 Product Introduction 4 .......................................................................................

1-1 Motherboard Layout 4 .........................................................................................

Chapter 2 Hardware Installation 6 .....................................................................................

2-1 Installation Precautions 6 ....................................................................................

2-2 Product Specications ...................................................................................... 7

2-3 Installing the CPU and CPU Cooler 10 ...............................................................

2-4 Installing the Memory 13 .....................................................................................

2-5 Installing an Expansion Card 14 .........................................................................

2-6 Back Panel Connectors 15 ..................................................................................

2-7 Internal Connectors 17 ........................................................................................

Chapter 3 BIOS Setup 28 ..................................................................................................

Chapter 4 Installing the Operating System and Drivers 30 ................................................

Regulatory Notices 31 ....................................................................................................

Contact Us 32 ................................................................................................................

- 4 -

1-1 Motherboard Layout

Chapter 1 Product Introduction

Temperature sensor

CPU_FAN

LGA1700

H610M H

F_AUDIO

BAT

ATX_12V_2X4

Intel® H610

CODEC

CLR_CMOS

M_BIOS

PCIEX16

80 60

PCIEX1

iTE®

Super I/O

GbE LAN

Chip

F_USB1 F_PANEL

SPI_TPM

M2P_SB

SYS_FAN2

F_USB2

USB 2.0 Hub

COM LED_C

KB_MS

AUDIO

R_U32

VGA

HDMI

USB_LAN

R_USB20

SYS_FAN1

ATX

F_U32

DDR5_A1

DDR5_B1

5 4

SATA3

7 6

SATA3

- 5 -

Temperature sensor

CPU_FAN

LGA1700

ATX

H610M H V2 DDR4

F_AUDIO

BAT

ATX_12V_2X4

Intel® H610

CODEC

CLR_CMOS

M_BIOS

PCIEX16

80 60

PCIEX1

iTE®

Super I/O

GbE LAN

Chip

F_USB1 F_PANEL

SPI_TPM

F_U32

DDR4_2

DDR4_1

M2P_SB

6 7

4 5

SATA3

SYS_FAN2

F_USB2

USB 2.0 Hub

COM LED_C

KB_MS

AUDIO

R_U32

VGA

HDMI

USB_LAN

R_USB20

SYS_FAN1

- 6 -

2-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can become

damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's

manual and follow these procedures:

•Prior to installation, make sure the chassis is suitable for the motherboard.

•Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or

warranty sticker provided by your dealer. These stickers are required for warranty validation.

•Always remove the AC power by unplugging the power cord from the power outlet before

installing or removing the motherboard or other hardware components.

•When connecting hardware components to the internal connectors on the motherboard, make

sure they are connected tightly and securely.

•When handling the motherboard, avoid touching any metal leads or connectors.

•It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic

components such as a motherboard, CPU or memory. If you do not have an ESD wrist strap,

keep your hands dry and rst touch a metal object to eliminate static electricity.

•Prior to installing the motherboard, please have it on top of an antistatic pad or within an

electrostatic shielding container.

•Before connecting or unplugging the power supply cable from the motherboard, make sure

the power supply has been turned off.

•Before turning on the power, make sure the power supply voltage has been set according to

the local voltage standard.

•Before using the product, please verify that all cables and power connectors of your hardware

components are connected.

•To prevent damage to the motherboard, do not allow screws to come in contact with the

motherboard circuit or its components.

•Make sure there are no leftover screws or metal components placed on the motherboard or

within the computer casing.

•Do not place the computer system on an uneven surface.

•Do not place the computer system in a high-temperature or wet environment.

•Turning on the computer power during the installation process can lead to damage to system

components as well as physical harm to the user.

•If you are uncertain about any installation steps or have a problem related to the use of the

product, please consult a certied computer technician.

•If you use an adapter, extension power cable, or power strip, ensure to consult with its installation

and/or grounding instructions.

Chapter 2 Hardware Installation

- 7 -

2-2 ProductSpecications

CPU LGA1700 socket: Support for 13th Generation Intel® Core™ Processors and

12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors

(Go to GIGABYTE's website for the latest CPU support list.)

L3 cache varies with CPU

Chipset Intel® H610 Express Chipset

Memory 13th Generation Intel® Core™ i9/i7 processors:

Support for DDR5 5600/5200/4800/4400 MT/s memory modules

 13th Generation Intel® Core ™ i5/i3 and 12th Generation Intel® Core™, Pentium®

Gold and Celeron® Processors:

Support for DDR5 4800/4400 MT/s memory modules

Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modulesk

 2 x DDR DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity)

of system memory

Dual channel memory architecture

 Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in

non-ECC mode)

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Prole (XMP) memory modules

(Go to GIGABYTE's website for the latest supported memory speeds and memory

modules.)

Onboard

Graphics

Integrated Graphics Processor-Intel® HD Graphics support:

- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz

- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.0 version and HDCP 2.3.

(Graphics specications may vary depending on CPU support.)

Audio Realtek® Audio CODEC

High Denition Audio

2/4/5.1/7.1-channel

* You can change the functionality of an audio jack using the audio software. To congure

7.1-channel audio, access the audio software for audio settings.

LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps)

Expansion Slots CPU:

- 1 x PCI Express p7-x16 slot, supporting PCIe 4.0 and running at x16

Chipset:

- 1 x PCI Express p7-x1 slot, supporting PCIe 3.0 and running at x1

Storage Interface Chipset:

- 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD

support)

- 4 x SATA 6Gb/s connectors

j Only for H610M H.

k Only for H610M H V2 DDR4.

- 8 -

USB Chipset:

- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through

the internal USB header)

- 4 x USB 2.0/1.1 ports on the back panel

Chipset+USB 2.0 Hub:

- 4 x USB 2.0/1.1 ports available through the internal USB headers

Internal

Connectors

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

2 x system fan headers

1 x M.2 Socket 3 connector

4 x SATA 6Gb/s connectors

1 x RGB LED strip header

1 x front panel header

1 x front panel audio header

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI

2.0 module only)

1 x serial port header

1 x Clear CMOS jumper

Back Panel

Connectors

1 x PS/2 keyboard port

1 x PS/2 mouse port

1 x D-Sub port

1 x HDMI port

2 x USB 3.2 Gen 1 ports

4 x USB 2.0/1.1 ports

1 x RJ-45 port

3 x audio jacks

I/O Controller iTE® I/O Controller Chip

Hardware

Monitor

Voltage detection

Temperature detection

Fan speed detection

Water cooling ow rate detection

Fan fail warning

Fan speed control

* Whether the fan speed control function is supported will depend on the cooler you

install.

BIOS 1 x 128 Mbit ash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

- 10 -

2-3 Installing the CPU and CPU Cooler

Read the following guidelines before you begin to install the CPU:

•Make sure that the motherboard supports the CPU.

(Go to GIGABYTE's website for the latest CPU support list.)

•Always turn off the computer and unplug the power cord from the power outlet before installing the

CPU to prevent hardware damage.

•Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or you may

locate the notches on both sides of the CPU and alignment keys on the CPU socket.)

•Apply an even and thin layer of thermal grease on the surface of the CPU.

•Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and damage

of the CPU may occur.

•Set the CPU host frequency in accordance with the CPU specications. It is not recommended

that the system bus frequency be set beyond hardware specications since it does not meet the

standard requirements for the peripherals. If you wish to set the frequency beyond the standard

specications, please do so according to your hardware specications including the CPU, graphics

card, memory, hard drive, etc.

A. Note the CPU Orientation

Note the alignment keys on the motherboard CPU socket and the notches on the CPU.

Alignment Key

LGA1700 CPU Socket

Triangle Pin One Marking

of the CPU Socket

Notch

LGA1700 CPU

Triangle Pin One

Marking on the CPU

Do not remove the CPU socket cover before inserting the CPU. It may pop off from the load

plate automatically after you insert the CPU and close the load plate.

&Please visit GIGABYTE's website for details on hardware installation.

http://www.gigabyte.com/WebPage/210/quick-guide.html?m=sw

- 12 -

C. Installing the CPU Cooler

Be sure to install the CPU cooler after installing the CPU. (Actual installation process may differ depending the

CPU cooler to be used. Refer to the user's manual for your CPU cooler.)

Apply an even and thin layer of thermal

grease on the surface of the installed CPU.

Place the cooler atop the CPU, aligning the

four push pins through the pin holes on the

motherboard. Push down on the push pins

diagonally.

Finally, attach the power connector of

the CPU cooler to the CPU fan header

(CPU_FAN) on the motherboard.

CPU_FAN

- 13 -

2-4 Installing the Memory

Read the following guidelines before you begin to install the memory:

•Make sure that the motherboard supports the memory. It is recommended that memory of the same

capacity, brand, speed, and chips be used. (Go to GIGABYTE's website for the latest supported

memory speeds and memory modules.)

•Always turn off the computer and unplug the power cord from the power outlet before installing the

memory to prevent hardware damage.

•Memory modules have a foolproof design. A memory module can be installed in only one direction.

If you are unable to insert the memory, switch the direction.

DualChannelMemoryConguration

This motherboard provides two memory sockets and supports Dual Channel Technology. After the memory

is installed, the BIOS will automatically detect the specications and capacity of the memory. Enabling Dual

Channel memory mode will double the original memory bandwidth.

The two memory sockets are divided into two channels and each channel has one memory socket as following:

Channel A: DDR5_A1j k, DDR4_1

Channel B: DDR5_B1 , DDR4_2j k

Due to CPU limitations, read the following guidelines before installing the memory in Dual Channel mode.

1. Dual Channel mode cannot be enabled if only one memory module is installed.

2. When enabling Dual Channel mode with two memory modules, it is recommended that memory of the

same capacity, brand, speed, and chips be used.

DDR5_A1j, DDR4_1k

DDR5_B1j, DDR4_2k

j Only for H610M H.

k Only for H610M H V2 DDR4.

- 14 -

2-5 Installing an Expansion Card

Read the following guidelines before you begin to install an expansion card:

•Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

•Always turn off the computer and unplug the power cord from the power outlet before installing an

expansion card to prevent hardware damage.

Follow the steps below to correctly install your expansion card in the expansion slot.

1. Locate an expansion slot that supports your card. Remove the metal slot cover from the chassis back panel.

2. Align the card with the slot, and press down on the card until it is fully seated in the slot.

3. Make sure that the expansion card is fully seated in its slot.

4. Secure the card's metal bracket to the chassis back panel with a screw.

5. After installing all expansion cards, replace the chassis cover(s).

6. Turn on your computer. If necessary, go to BIOS Setup to make any required BIOS changes for your

expansion card(s).

7. Install the driver provided with the expansion card in your operating system.

PCIEX16 Slot

- 15 -

PS/2 Keyboard and PS/2 Mouse Port

Use the upper port (green) to connect a PS/2 mouse and the lower port (purple) to connect a PS/2 keyboard.

D-Sub Port

The D-Sub port supports a 15-pin D-Sub connector and supports a maximum resolution of 1920x1200@60 Hz

(the actual resolutions supported depend on the monitor being used). Connect a monitor that supports D-Sub

connection to this port.

HDMI Port

The HDMI port is HDCP 2.3 compliant and supports Dolby TrueHD and DTS

HD Master Audio formats. It also supports up to 192KHz/24bit 7.1-channel

LPCM audio output. You can use this port to connect your HDMI-supported monitor. The maximum

supported resolution is 4096x2160@60 Hz, but the actual resolutions supported are dependent on the

monitor being used.

2-6 Back Panel Connectors

After installing the HDMI device, make sure to set the default sound playback device to HDMI.

(The item name may differ depending on your operating system.)

•When removing the cable connected to a back panel connector, rst remove the cable from your

device and then remove it from the motherboard.

•When removing the cable, pull it straight out from the connector. Do not rock it side to side to

prevent an electrical short inside the cable connector.

USB 2.0/1.1 Port

The USB port supports the USB 2.0/1.1 specication. Use this port for USB devices.

USB 3.2 Gen 1 Port

The USB 3.2 Gen 1 port supports the USB 3.2 Gen 1 specication and is compatible to the USB 2.0

specication. Use this port for USB devices.

RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describes the states of the LAN port LEDs.

Activity LEDSpeed LED

LAN Port

Activity LED:Speed LED:

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

Off 10 Mbps data rate

State Description

Blinking Data transmission or receiving is occurring

Off No data transmission or receiving is occurring

- 19 -

1/2) ATX_12V_2X4/ATX (2x4 12V Power Connector and 2x12 Main Power Connector)

With the use of the power connector, the power supply can supply enough stable power to all the components

on the motherboard. Before connecting the power connector, rst make sure the power supply is turned

off and all devices are properly installed. The power connector possesses a foolproof design. Connect the

power supply cable to the power connector in the correct orientation.

The 12V power connector mainly supplies power to the CPU. If the 12V power connector is not connected,

the computer will not start.

To meet expansion requirements, it is recommended that a power supply that can withstand high

power consumption be used (500W or greater). If a power supply is used that does not provide the

required power, the result can lead to an unstable or unbootable system.

ATX:

Pin No. Pin No.Denition Denition

1 3.3V 13 3.3V

2 3.3V 14 -12V

3 GND 15 GND

4 +5V 16 PS_ON (soft On/Off)

5 GND 17 GND

6 +5V 18 GND

7 GND 19 GND

8 Power Good 20 NC

9 5VSB (stand by +5V) 21 +5V

10 +12V 22 +5V

11 +12V (Only for 2x12-pin

ATX)

23 +5V (Only for 2x12-pin ATX)

12 3.3V (Only for 2x12-pin ATX) 24 GND (Only for 2x12-pin ATX)

ATX_12V_2X4:

Pin No. Denition

1 GND (Only for 2x4-pin 12V)

2 GND (Only for 2x4-pin 12V)

3 GND

4 GND

5 +12V (Only for 2x4-pin 12V)

6 +12V (Only for 2x4-pin 12V)

7 +12V

8 +12V

131

2412

ATX

ATX_12V_2X4

- 20 -

•Be sure to connect fan cables to the fan headers to prevent your CPU and system from

overheating. Overheating may result in damage to the CPU or the system may hang.

•These fan headers are not conguration jumper blocks. Do not place a jumper cap on the headers.

3/4) CPU_FAN/SYS_FAN1/SYS_FAN2 (Fan Headers)

All fan headers on this motherboard are 4-pin. Most fan headers possess a foolproof insertion design.

When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is

the ground wire). The speed control function requires the use of a fan with fan speed control design. For

optimum heat dissipation, it is recommended that a system fan be installed inside the chassis.

CPU_FAN

SYS_FAN1

Pin No. Denition

1 GND

2 Voltage Speed Control

3 Sense

4 PWM Speed Control

Connector CPU_FAN SYS_FAN1 SYS_FAN2

Maximum Current 2A 2A 2A

Maximum Power 24W 24W 24W

SYS_FAN2

Before installing the devices, be sure to turn off the devices and your computer. Unplug the power

cord from the power outlet to prevent damage to the devices.

For how to turn on/off the lights of the LED strip, please navigate to the "Unique Features" page

of GIGABYTE's website.

5) LED_C (RGB LED Strip Header)

The header can be used to connect a standard 5050 RGB LED strip (12V/G/R/B), with maximum power

rating of 2A (12V) and maximum length of 2m.

Pin No. Denition

1 12V

2 G

3 R

4 B

RGB LED Strip

12V

Connect your RGB LED strip to

the header. The power pin (marked

with a triangle on the plug) of the

LED strip must be connected to

Pin 1 (12V) of this header. Incorrect

connection may lead to the damage

of the LED strip.

- 21 -

6) SATA3 4/5/6/7 (SATA 6Gb/s Connectors)

The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA

1.5Gb/s standard. Each SATA connector supports a single SATA device.

Pin No. Denition

1 GND

2 TXP

3 TXN

4 GND

5 RXN

6 RXP

7 GND

To enable hot-plugging for the SATA ports, please navigate to the "BIOS Setup" page of GIGABYTE's

website and search for "SATA Conguration" for more information.

SATA3

6 7

4 5

SATA3 5

SATA3 7

H610M H

H610M H V2 DDR4

- 22 -

7) M2P_SB (M.2 Socket 3 Connector)

The M.2 connector on the motherboard supports only M.2 PCIe SSDs.

Follow the steps below to correctly install an M.2 SSD in the M.2 connector.

Step 1:

Locate the proper mounting hole for the M.2 SSD to be installed and then install the mounting clip rst.

Step 2:

Pull the clip's tab up and out of the mounting hole. Slide the M.2 SSD into the connector at an angle.

Step 3:

Press the M.2 SSD down and then secure it by pressing the clip's tab into the mounting hole.

* Types of M.2 SSDs supported by the M.2 connector:

M.2 PCIe p22-x4 SSD M.2 PCIe p22-x2 SSD M.2 SATA SSD

M2P_SB a a r

80 60

- 23 -

The front panel design may differ by chassis. A front panel module mainly consists of power switch,

reset switch, power LED, hard drive activity LED, speaker and etc. When connecting your chassis

front panel module to this header, make sure the wire assignments and the pin assignments are

matched correctly.

8) F_PANEL (Front Panel Header)

Connect the power switch, reset switch, speaker, chassis intrusion switch/sensor and system status indicator

on the chassis to this header according to the pin assignments below. Note the positive and negative pins

before connecting the cables.

•PW (Power Switch):

Connects to the power switch on the chassis front panel. You may congure the way to turn off your

system using the power switch (please navigate to the "BIOS Setup" page of GIGABYTE's website and

search for "Soft-Off by PWR-BTTN" for more information).

•SPEAK (Speaker):

Connects to the speaker on the chassis front panel. The system reports system startup status by issuing

a beep code. One single short beep will be heard if no problem is detected at system startup.

•HD (Hard Drive Activity LED):

Connects to the hard drive activity LED on the chassis front panel. The LED is on when the hard drive

is reading or writing data.

•RES (Reset Switch):

Connects to the reset switch on the chassis front panel. Press the reset switch to restart the computer

if the computer freezes and fails to perform a normal restart.

•CI (Chassis Intrusion Header):

Connects to the chassis intrusion switch/sensor on the chassis that can detect if the chassis cover has

been removed. This function requires a chassis with a chassis intrusion switch/sensor.

•NC: No connection.

•PLED/PWR_LED (Power LED):

Connects to the power status indicator on the chassis front panel. The LED

is on when the system is operating. The LED is off when the system is in S3/

S4 sleep state or powered off (S5).

System Status LED

S0 On

S3/S4/S5 Off

PLED-

PW-

SPEAK+

SPEAK-

PLED+

PW+

HD-

RES+

HD+

RES-

Hard Drive

Activity LED

Reset

Switch

Power LED

CI-

CI+

Power LED

Chassis Intrusion

Header

Power Switch Speaker

PWR_LED-

PWR_LED+

- 24 -

9) F_AUDIO (Front Panel Audio Header)

The front panel audio header supports High Denition audio (HD). You may connect your chassis front

panel audio module to this header. Make sure the wire assignments of the module connector match the

pin assignments of the motherboard header. Incorrect connection between the module connector and the

motherboard header will make the device unable to work or even damage it.

Some chassis provide a front panel audio module that has separated connectors on each wire

instead of a single plug. For information about connecting the front panel audio module that has

different wire assignments, please contact the chassis manufacturer.

10) F_U32 (USB 3.2 Gen 1 Header)

The header conforms to USB 3.2 Gen 1 and USB 2.0 specication and can provide two USB ports. For

purchasing the optional 3.5" front panel that provides two USB 3.2 Gen 1 ports, please contact the local

dealer.

Pin No. Pin No.Denition Denition

1 VBUS D2+11

2 SSRX1- 12 D2-

3 SSRX1+ 13 GND

4 GND 14 SSTX2+

5 SSTX1- 15 SSTX2-

6 SSTX1+ 16 GND

7 GND 17 SSRX2+

8 D1- 18 SSRX2-

9 D1+ 19 VBUS

10 NC 20 No Pin

20 1

1011

Pin No. Denition

1 MIC L

2 GND

3 MIC R

4 NC

5 Head Phone R

6 MIC Detection

7 SENSE_SEND

8 No Pin

9 Head Phone L

10 Head Phone Detection

- 26 -

Pin No. Denition

1Data Output

2Power (3.3V)

3No Pin

4NC

5Data Input

6CLK

7Chip Select

8GND

9IRQ

10 NC

11 NC

12 RST

13) SPI_TPM (Trusted Platform Module Header)

You may connect an SPI TPM (Trusted Platform Module) to this header.

14) CLR_CMOS (Clear CMOS Jumper)

Use this jumper to clear the BIOS conguration and reset the CMOS values to factory defaults. To clear

the CMOS values, use a metal object like a screwdriver to touch the two pins for a few seconds.

•Always turn off your computer and unplug the power cord from the power outlet before clearing

the CMOS values.

•After system restart, go to BIOS Setup to load factory defaults (select Load Optimized Defaults) or

manually congure the BIOS settings (please navigate to the "BIOS Setup" page of GIGABYTE's

website for more information).

Open: Normal

Short: Clear CMOS Values

Specyfikacje produktu

Marka:	Gigabyte
Kategoria:	płyta główna
Model:	H610M H
Kolor produktu:	Brązowy
Wysokość produktu:	35 mm
Szerokość produktu:	230 mm
Głębokość produktu:	215 mm
Szerokość opakowania:	265 mm
Wysokość opakowania:	54 mm
Głębokość opakowania:	265 mm
Okres gwarancji:	3 lat(a)
Wyjścia słuchawkowe:	3
Obsługiwany typ USB:	USB Typu-A
Kraj pochodzenia:	Chiny
Technologia baterii:	Lithium-Manganese Dioxide (LiMnO2)
Obsługiwane systemy operacyjne Windows:	Windows 10 x64, Windows 11 x64
Przeznaczenie:	PC
Ilość portów Ethernet LAN (RJ-45):	1
Wi-Fi:	Nie
Przewody:	SATA
Kanały wyjścia audio:	7.1 kan.
Liczba portów USB 2.0:	4
Przewodowa sieć LAN:	Tak
Waga wraz z opakowaniem:	849 g
Rodzaj baterii:	CR2032
Ilość obsługiwanych rozmiarów dysków pamięci:	5
Obsługiwane rodzaje dysków:	HDD & SSD
Producent procesora:	Intel
Ilość portów USB 3.2 Gen 1 (3.1 Gen 1) Typu-A:	2
Obsługiwane rodzaje pamięci:	DDR5-SDRAM
Typ slotów pamięci:	DIMM
Liczba gniazd pamięci:	2
Bez kody korekcyjnego:	Tak
Obsługiwane prędkości zegara pamięci:	4400,4800,5200,5600 MHz
Maksymalna pojemność pamięci:	64 GB
Obsługa kanałów pamięci:	Dwukanałowy
Gniazdo procesora:	LGA 1700
Procesor:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium G
Rodzina płyt z chipsetami:	Intel
Rodzaj płyty:	micro ATX
Układ płyty głównej:	Intel H610 Express
Typ BIOS:	UEFI AMI
Zworka clear CMOS:	Tak
PCI Express x1 slots:	1
PCI Express x16 gniazda:	1
Liczba gniazd M.2 (M):	1
Gniazdo zasilania ATX (24-pin):	Tak
Złącze zasilacza EPS (8-pin):	Tak
Ilość złączy SATA III:	4
Ilość gniazd USB 2.0:	2
Łącza USB 3.2 Gen 1 (3.1 Gen 1):	1
Gniazdo wentylatora procesora:	Tak
Ilość gniazd w podstawie wentylatora:	2
Złącze audio na przednim panelu:	Tak
Złącze panelu przedniego:	Tak
Złącze TPM:	Tak
Liczba portów PS/2:	2
Ilość portów HDMI:	1
Mikrofon:	Tak
Baterie w zestawie:	Tak
Zawiera sterowniki:	Tak
Pamięć niebuforowana:	Tak
Wspierane interfejsy dysków twardych:	M.2, SATA III
Liczba obsługiwanych HDD:	4
Obsługa przetwarzania równoległego:	Nieobsługiwany
Maks. rozdzielczość:	4096 x 2160 px
Wersja DirectX:	12.0
Rodzaj interfejsu sieci Ethernet:	Gigabit Ethernet
Łączna liczba złączy SATA:	4
Liczba portów VGA (D-Sub):	1
HDCP:	Tak
Dołączone oprogramowanie:	Norton Internet Security (OEM version), LAN bandwidth management software
Produkty na skrzynię wysyłkową (wewnętrzną):	1 szt.
Obsługiwane gniazda procesora:	LGA 1700
Korekcja ECC:	Tak
Monitorowanie stanu komputera:	FAN, Temperature, Voltage
Złącze Serial port:	1
Złącze zasilania 12V:	Tak
LED RGB:	Tak
Rozmiar pamięci BIOS:	128 Mbit
Wersja ACPI:	5.0
Wersja interfejsu zarządzania pulpitem (DMI):	2.7
Wersja systemu BIOS (SMBIOS):	2.7
Maksymalna pamięć wewnętrzna wspierana przez procesor:	64 GB
Ilość komór baterii:	1
Waga baterii/akumulatora:	3 g
Obsługiwana prędkość zegara pamięci (maks.):	5600 MHz
Waga akumulatora litowego:	0.07 g
