For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
GA-H110M-S2PV DDR3
User's Manual
Rev. 1001
Copyright
© 2015 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or
by any means without GIGABYTE's prior written permission.
In order to assist in the use of this product, carefully read the User's Manual.
For product-related information, check on our website at: http://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means
the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard
BIOS, drivers, or when looking for technical information.
Example:
Motherboard
GA-H110M-S2PV DDR3
Aug. 28, 2015
Aug. 28, 2015
Motherboard
GA-H110M-S2PV DDR3
- 3 -
Table of Contents
GA-H110M-S2PV DDR3 Motherboard Layout 4 ................................................................
Chapter 1 Hardware Installation 5 .....................................................................................
1-1 Installation Precautions 5 ....................................................................................
1-2 ProductSpecications ...................................................................................... 6
1-3 Installing the CPU 8 ............................................................................................
1-4 Installing the Memory 9 .......................................................................................
1-5 Installing an Expansion Card 9 ...........................................................................
1-6 Back Panel Connectors 9 ....................................................................................
1-7 Internal Connectors ........................................................................................ 11
Chapter 2 BIOS Setup 17 ..................................................................................................
2-1 Startup Screen 17 ...............................................................................................
2-2 M.I.T. .............................................................................................................. 18
2-3 System Information 23 ........................................................................................
2-4 BIOS Features 24 ...............................................................................................
2-5 Peripherals ..................................................................................................... 27
2-6 Chipset ........................................................................................................... 29
2-7 Power Management 30 .......................................................................................
2-8 Save & Exit 32 .....................................................................................................
Chapter 3 Appendix 33 ......................................................................................................
Drivers Installation 33 .....................................................................................................
Regulatory Statements 34 ..............................................................................................
Contact Us 36 ................................................................................................................


Specyfikacje produktu

Marka: Gigabyte
Kategoria: płyta główna
Model: GA-H110M-S2PV DDR3
Rodzaj zasilania: ATX
Szerokość produktu: 244 mm
Głębokość produktu: 180 mm
Wyjścia słuchawkowe: 2
Przeznaczenie: PC
Ilość portów Ethernet LAN (RJ-45): 1
Kanały wyjścia audio: 5.1 kan.
Liczba portów USB 2.0: 4
Przewodowa sieć LAN: Tak
Producent procesora: Intel
Ilość portów USB 3.2 Gen 1 (3.1 Gen 1) Typu-A: 2
Obsługiwane rodzaje pamięci: DDR3-SDRAM, DDR3L-SDRAM
Typ slotów pamięci: DIMM
Bez kody korekcyjnego: Tak
Obsługiwane prędkości zegara pamięci: 1333,1600 MHz
Maksymalna pojemność pamięci: 32 GB
Obsługa kanałów pamięci: Dwukanałowy
Gniazdo procesora: LGA 1151 (Socket H4)
Procesor: Intel Celeron, Intel Pentium
Rodzina płyt z chipsetami: Intel
Rodzaj płyty: micro ATX
Układ płyty głównej: Intel® H110
Typ BIOS: UEFI AMI
Zworka clear CMOS: Tak
PCI Express x1 slots: 1
PCI Express x16 gniazda: 1
Gniazdo zasilania ATX (24-pin): Tak
Ilość złączy SATA III: 4
Ilość gniazd USB 2.0: 2
Łącza USB 3.2 Gen 1 (3.1 Gen 1): 1
Gniazdo wentylatora procesora: Tak
Liczba portów PS/2: 1
Ilość portów DVI-D: 1
Mikrofon: Tak
Układ audio: Realtek ALC887
Wspierane interfejsy dysków twardych: SATA III
Rodzaj interfejsu sieci Ethernet: Gigabit Ethernet
Złącze wentylatora: Tak
Liczba portów VGA (D-Sub): 1
Dołączone oprogramowanie: Norton Internet Security (OEM version)\ncFosSpeed
Korekcja ECC: Tak
Monitorowanie stanu komputera: CPU, FAN, Temperature, Voltage
Złącze Serial port: 1
Rozmiar pamięci BIOS: 128 Mbit
Wersja ACPI: 5.0
Wejście audio CD/AUX: Tak
Sloty PCI: 2
Port równoległy przez wewnętrzny nagłówek: Tak
