Strona 1/8
1
POWER PER CHANNEL
• 4 x 150 wRMS into 4 ohms @ 1% THD
• 4 x 200 wRMS into 2 ohms @ 1% THD
• 2 x 400 wRMS Bridged into 4 ohms @ 1% THD
DO NOT Bridge into 2 ohms
All power ratings are at 14.4v DC.
ROUTE SWITCH
• 1+2 = All four RCA inputs are used.
• 3+4 = Input signal on channels 3+4 are routed to channels 1+2. Use this mode when you need a band pass filter
on all four channels.
Recommended when bridging channels 1, 2, 3, 4.
The controls still function.LEVEL
• Copy = Input signal and filters on channels 3+4 are copied to channels 1+2. Use this mode when you need a band
pass filter on all four channels.
Recommended when bridging channels 1,2,3,4.
The controls still function. LEVEL
CHANNELS 1 & 2 CROSSOVER CONFIGURATION
• Flat: Full Range Signal. No crossover filter used.
• HP: Activates the High Pass Filter for a midbass or tweeter.
CHANNELS 3 & 4 CROSSOVER CONFIGURATION
• Flat: Full Range Signal. No crossover filter used.
• HP: Activates the High Pass filter.
• LP/BP: Activates the selection of either a Low Pass filter for woofer or a Band Pass filter for midrange.
• MONO Mode: Inputs 3+4 are mixed to mono for bridge mode operation. If 1+2 ROUTE is set to COPY then 1+2
will also be mono subwoofer and the remote volume control will control level.
The subwoofer remote volume control is activated. There is a clip distortion light on the remote volume control.
If you see this light on, reduce volume until the light goes out so that you do not damage your speaker.
AUTOMATIC POWER TURN ON/OFF
1. The best way to automatically turn the amplifier power on and off is to use the REM wire from your source radio
connected to the REM amplifier terminal.Band Pass for a subwoofer or midbass of a 3 way speaker.
2. If your original equipment stereo or source radio has a BTL amplifier then the RCA inputs have an auto turn
on sensing circuit. When you connect the high level BTL speaker wires to the RCA input the REM wire is not
necessary.
FDP 4.600 V2: FOUR CHANNEL AMPLIFIER
OPERATION / CONFIGURATION MANUAL
2
RCA INPUT, BOTH LOW LEVEL AND HIGH LEVEL
• The amplifier LEVEL control has sufficient adjustment range for both low level and high level input into the RCA
jacks. A factory source radio that does not have RCA output, using the wires that are connected to the speakers,
can be directly connected to the RCA jacks when the amplifier control is adjusted to 8V.LEVEL
SETTING LEVEL
• The best way to set system levels is to use a D’Amore Engineering DD-1 and test signals.
Follow their gain overlap instructions.
• Set the amplifier control to minimum before you turn on the amplifier for the first time.LEVEL
• For lowest distortion and lowest noise the amplifier should be set at the lowest setting that yields LEVEL
sufficient loudness without distortion. For lowest noise your source radio volume control should be near
maximum that does cause distortion.NOT
• To find the best amplifier setting if you are NOT using a DD-1: LEVEL
1) With the amplifier at minimum, slowly increase the source radio volume until you hear distortion. Then LEVEL
turn it down to until the distortion stops.
2) Next, slowly turn up the amplifier control to the maximum desired loudness, or until the red LED LEVEL
light flashes on the music’s ocassional peaks. (The LED turns on when there is distortion that can damage your
speakers.) Listen very carefully and turn down the amplifier control if you hear any distortion.LEVEL
FDP 4.600 V2 CONFIGURATION EXAMPLES
4 CHANNEL STEREO NON-BRIDGED (SEE GRAPHIC B1)
• If you have four input wires from the source deck, plug them into inputs 1+2 and 3+4.
Set ROUTE switch to 1+2.
• If you have two input wires from the source deck, plug them into inputs 3+4.
Set ROUTE switch to 3+4.
Set the switch to STEREO.
• If you are NOT using a subwoofer set all switches to flat. If you hear distortion in your woofers set all switch to
HP and adjust all HP frequency until the distortion goes away, this will probably be around 50 Hz to 70 Hz.
RADIO FLAT or HP50Hz
1+250Hz FLAT or HP
STEREO
B1 (4 CHANNEL STEREO NON-BRIDGED)
XOVER
XOVER XOVER
XOVER
3
IF YOU ARE USING TWO SUBWOOFERS (SEE GRAPHIC B2)
• Put your woofer/tweeters on channel 1+2.
Set 1+2 switch to HP.
Adjust 1+2 HP frequency to 70 Hz.
• Subwoofers on channel 3+4.
Set 3+4 switch to LP/BP.
Set 3+4 switch to LP.
Adjust 3+4 LP frequency to 70 Hz.
Set the switch to MONO.
Plug in the remote sub control.
RADIO LP
LP/BP
70Hz
3+470Hz
HP
MONO
B2 (IF YOU ARE USING TWO SUBWOOFERS)
+ –
SUBWOOFER
+ –
SUBWOOFER
REMOTE SUB CONTROL
XOVER
XOVER
3 CHANNEL WITH BRIDGED SUBWOOFER (SEE GRAPHIC B3)
• DO NOT use a 2 Ohm Subwoofer.
• If you have four input wires from the source deck plug them into inputs 1+2 and 3+4.
Set ROUTE switch to 1+2.
• If you have two input wires from the source deck plug them into inputs 3+4.
Set ROUTE switch to 3+4.
• Put your woofer/tweeters on channel 1+2.
Set 1+2 switch to HP.
Adjust 1+2 HP frequency to 70 Hz.
• Your subwoofer is wired to channel 3+ and channel 4-.
Set 3+4 switch to LP/BP.
Set 3+4 switch to LP.
Adjust 3+4 LP frequency to 70 Hz.
Set the switch to MONO.
Plug in the remote sub control.
