Strona 1/4
12/29/24
IGP-1031, 10-Port Gigabit PoE
Industrial Switch, DIN-Rail,
-40°C to 75°C
Product Images
Short Description
10/100/1000Mbps wire speed transmission and reception
Built-in 8 PoE ports for PoE devices
8 Gigabit Ethernet ports and 2 Gigabit SFP slots
6KV surge protection level on each port
ESD and surge protection
Supports the PoE auto-check function,which is specially designed to solve the problems
of equipment frozen. It can automatically detect the frozen PD equipment and restart the
port's output of PoE, and restart the PD device. It gently reduces the maintenance
diculty of engineering.
Powerful DIP switch button conguration for PoE Auto-Check, and Default mode / VLAN
mode features.
22/29/24
10/100/1000Mbps wire speed transmission and reception
Built-in 8 PoE ports for PoE devices
8 Gigabit Ethernet ports and 2 Gigabit SFP slots
6KV surge protection level on each port
ESD and surge protection
Supports the PoE auto-check function,which is specially designed to solve the
problems of equipment frozen. It can automatically detect the frozen PD
equipment and restart the port's output of PoE, and restart the PD device. It gently
reduces the maintenance diculty of engineering.
Powerful DIP switch button conguration for PoE Auto-Check, and Default mode /
VLAN mode features.
Description
LevelOne IGP-1031 Industry Ethernet Switch provides 8 PoE ports 10/100/1000Base plus
2 port Gigabit SFP to enable high speed network at mission-critical environment. With the
industrial standard DIN-rail mount; this switch can be easily installed in the cabinet, plus
the clearly visible status LEDs provide simple monitoring of port link activity. Moreover,
the SFP slots support pluggable modules that enabling you to choose from a variety of
transceivers. This switch is Power Sourcing Equipment (PSE), and it is fully complied with
IEEE802.3af/at PoE standard at maximum 30W each port power budget. It helps to save
infrastructure wiring costs dramatically by eliminating electric wiring and less UPS
needed. Also, it is compatible with IEEE802.3af standard PD devices.
32/29/24
Additional Information
Gigabit RJ45/SFP combo 2
Gigabit RJ45 8
802.3af/at PoE 8
Color Black
EAN 4015867223963
Model Number IGP-1031
Features
PoE Auto-check : If detect the frozen PD device,
switch will restart it. IEEE 802.3af/at MTBF: 400k
hours
Data rate Gigabit Ethernet
PoE Power Budget Total 240.00
PoE Supported Yes
Concurrent ports Total 10.00
Fanless Yes
Manageable No
Grade Industrial
Approval and Compliance CE/FCC Surge: 6KV, standard: IEC61000-4-5 ESD:
8KV: contact/15KV: air, standard:IEC61000-4-2
Operating humidity 0% RH ~ 95% RH
Operating temperature -40°C ~ 75°C
Storage humidity 0% RH ~ 95% RH
Storage temperature -40°C ~ 85°C
Package Contents IGP-1031 Power Terminal Block Quick
Installation Guide
Dimensions (W x D x H) 165 x 114 x 50 mm
Product weight (kg) 1
Backplane (Gbps) 20Gbps
Specyfikacje produktu
| Marka: | Equip |
| Kategoria: | Schakelaar |
| Model: | IGP-1031 |
