Rev.101017BR www.elitescreens.com 1
Yard Maste
Yard Maste
Yard Maste
Yard MasteYard Master
r
r
r r 2
2
2
2 2 Series
Series
Series
SeriesSeries
Indoor/Outdoor Portable Projection Screen
User’s Guide
Thank you for choosing the Yard Master 2 portable projection Please read through th ! screen is user guide
before utilizing the screen. Correct usage and maintenance will nsure e a long product life
Care & Use Instructions
◆ Please be sure to distinguish between the front and back of the screen fabric when setting up the
projection screen. CineWhite® (front projection) has a black backing and WraithVeil (rear projection) is
labeled front, back.
◆ Be sure to use the screen only during a light breeze; it is not meant to withstand heavy winds. *Elite
Screens is not responsible for damages due to negligence resulting from misuse under weather
conditions and will void your warranty.
◆Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the
points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or
alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
◆After using the screen, disassemble it carrying bag provided. and store it in the
◆To avoid damage and injury, the screen should only be operated by adults.
Product Description
Design: The aluminum frame is designed to be light weight and easily operated making it easy to carry,
assemble and disassemble.
Rev.101017BR www.elitescreens.com 2
Screen Fabric: The screen fabric is attached to the rectangular frame and held in place by several press
studs, which ensure an evenly stretched and flat surface. The CineWhite® (front projection) and
WraithVeil (rear projection) screen materials are durable and can be folded many times without causing
damage or distortion to the surface.
Parts Diagram
A. Folding frame x1 B. Left and right folding legs x2 C. Screen material bag x1
D. Projection screen material x1 E. Knob screw x 2
F. Eyebolt x2
G p2-x2 . Rope H. Carrying Bag p2-x1 I . Stake p2-x4
Note: The parts above is subject to change without notice. list
Correct us of the projection screen will ensure better results.age viewing
For front projection, assemble and view the screen as indicated in Fig.1.
For rear projection, assemble and view the screen as indicated in Fig.2.
Frame Assembly and Screen Material Attachment
1. Take the folding frame (A) out of the carrying bag (H) and place it on a flat surface. Unfold the longer
sections first as shown in Fig.3-4
.
Fig. 3
Fig. 4
Rev.101017BR www.elitescreens.com 3
Fig.10
2. Unfold the frame until the latch on the hinge "clicks" into place. Repeat the procedure for the shorter
sections. -6)(Fig. 5
3. Make sure all 4 corners of the frame are at a 90° angle and the hinged support bar is straight and not
bending. (Fig. 7-9)
4 I．nsert the frame legs (B) s into the opening located at the left and
right bottom sides of the folding frame (A). Secure them by
fastening the hole. Next, knob screw (E) into the adjacent screw
the eyebolts (F) into the openings located at the top of the frame
(Fig.10).
5. Take the screen material (D) screen material bag (C)out of the and align the corners of the screen
material with the inside corners of the frame. Unfold as shown in the diagram (Fig.11-12).
6
. Once the screen material (D) is fully extended, secure the material by snapping the buttons onto the
frame studs as shown in Fig. 13-15. Fasten the buttons in the following order AB→CD→EF→GH.
Fig. 5
Fig.7
Fig.8
Fig.9
F 12 ig.
F .11 ig
F .13 ig
F 4 ig1
A
B
C
D
E
F
G
H
F .15 ig
Fig. 6
