MBO50 & MBO55
BUILT-IN MICROWAVE OVENS
Installation Instructions
Retention of this Instruction Book...
This Instruction Book must be kept handy for reference as it contains important details on the safe and
proper use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it behind, make sure this Book
is also provided so the new owner can become familiar with the appliance and safety warnings.
Fig. 1
Fig. 1b
Fig. 2
Fig. 3 Fig. 4
Fig. 5
Fig. 7
Fig. 6
REINFORCEMENT STRIP
TO BE FITTED FLUSH TO
GRILL AS SHOWN
REINFORCEMENT STRIP
TO BE POSITIONED
CENTRALLY ON THE GRILL
(A) (B) (C)
(D) (E) (F)
(G) (H) (K) (L)
= +
= + (N)(J) 1x(F)
(M) (N)
A.
Please read these instructions carefully before you begin
1. The microwave oven can be installed into a 600mm wide
Cabinet. The installation cavity must have the following
internal dimensions:
Height: 395mm (± 2mm)
Width: 562x570mm
Depth: At least 400mm
Vent: Min 45mm x 562mm applicable to all panels.
(Ensure the vent is not obstructed)
See Fig. 1.
2. The shelf must be able to support a weight of 15kg.
3. In the event of appliance failure, switch off the oven by
switching off at the wall switch and removing the mains plug
from the socket, or by isolating the supply from the main fuse-
box. Trim kit should be removed (see section E) prior to taking
out the oven from the cabinet.
Electrical Connections
The appliance is already fitted with a plug and may only be
connected to a correctly installed earthed socket. Only a qualified
electrician may install or relocate a socket outlet. The plug must be
accessible after installation unless an isolator switch is used to
disconnect all poles having a contact gap of at least 3mm in each
pole.
Contents
APaper template 1 piece
BCarrier rails 2 pieces
CFoam exhaust guide set 3 pieces
DBlanking plate 1 piece
EMetal exhaust guide 1 piece
FGrille 2 pieces
GSide trims 2 pieces
HScrews (short) 4 pieces
KScrews (long) 4 pieces
LCushions 2 pieces
MBlack Tape Strips 2 pieces
N Reinforcement Bracket 1 piece
JTop Grille (with metal strip) 1 piece
Please note that this part has to be assembled using 1 Grille (F)
and the Reinforcement Bracket (N). See Fig. 1b for assembly
instructions.
Also check that all the contents are available before
commencing work.
B.
Preparing the cupboard for installation
1. Mark the centre of the cabinet shelf. Place the paper template
(A) onto the shelf, ensuring that the arrow on the template is
on the centreline and flush to the front leading edge of the
cabinet shelf.
2. Using a 3mm drill bit, pre-drill the 4 holes marked on the
template for attaching the carrier rails. When this is done
remove the template.
3. (A)Fold template along the dotted line, reposition the
template to the centre of the cabinet shelf and mark around
the corners. Once completed remove the template.
4. (B)Fit the carrier rails onto the cabinet shelf using the 4 small
screws provided (H) (Fig. 3).
5. Assemble the foam exhaust guide pieces together by inter-
locking the tabs into the holes, to obtain the assembly shown
(Fig. 2).
6. Peel the backing strip off the adhesive side of the assembled
exhaust guide, then fit it to the cabinet using the left hand
edge of the left carrier rail to align the one side, then use the
lines drawn on the cabinet to align the other remaining parts
of the exhaust guide.
N.B. Access will be required to accommodate the plug
top/mains cable.
C.
Preparing the microwave oven for installation
1. Remove the 2 screws shown in from the underside of (Fig. 4)
the oven base below the door. Then use these screws to
attach the blanking plate to this area of the oven.(D)
2. Remove the screw at the rear right top of the oven (viewed
from behind the oven).
3. (L) Attach cushion strips to the front and rear flanges of the
oven exhaust guide (E). As shown in (Fig. 5).
4. (E)Hook the Oven exhaust guide into the rear panel of the
oven (see arrow - Fig. 5). Secure the Exhaust guide (E) onto
the rear panel of the oven using screw removed earlier. Then
fit black tape strips to the left and right flanges to seal this(M)
part to the top of the microwave oven. See (Fig. 5).
5. (B)Rest the microwave oven on the carrier rails . Plug the
power cord into the wall mains outlet via hole cut in the back
of the cabinet. Ensure that the feet of the oven are located
into the recesses.
N.B. Care should be taken when fitting the microwave oven,
so as not to pinch the foam pieces and the power cord during
installation. Therefore an assistant may be required.
D.
Attaching the Plastic Grilles and Side Trims
1. Centralise and align the frame pieces to the front of the
cabinet and mark the position of the screw holes, and then
drill holes using a 3mm drill bit.
2. Loosely attach the top and bottom grille pieces (F/J) to the
front of the cupboard using the screws provided as shown(K)
in (Fig. 6). Ensure that grille piece J is fitted at the top.
3. Hold the side trim pieces (G) against the oven and align the
top and bottom grill vents . Ensure there is an equal gap (F/J)
between the oven and the trim pieces.
4. Tighten up the screws (K).
5. Press and clip the side trims (G) into place, between the top
and bottom grills on the edge of the cabinet.
E.
Removing the Plastic Grills and Side Trims
Insert a flat bladed screwdriver into the slot of the side trim pieces
(G) and prise them off. See . Remove the screws fixing the(Fig. 6)
top and bottom grill vent pieces. Ensure that the screwdriver does
not slip as to avoid causing damage to the side trim pieces.
