I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Large Swing Arm Mounts
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
TS525TU
TS525TU Installation Instructions
2
DISCLAIMER
Milestone AV Technologies and its affiliated corporations and
subsidiaries (collectively "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
IMPORTANT SAFETY INSTRUCTIONS!
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING: Use this mounting system only for its intended
use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
WARNING: Never operate this mounting system if it is
damaged. Return the mounting system to a service center for
examination and repair.
WARNING: Do not use this product outdoors.
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
WARNING: The wall to which the mount is being attached
may have a maximum drywall thickness of 5/8" (1.6cm) when
installing to wood studs or hollow concrete block. If installing
to poured concrete, the wall CANNOT have ANY drywall
covering!
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached does not exceed 125 lbs (56.7 kg).
Use with products heavier than the maximum weight
indicated may result in collapse of the mount and its
accessories causing possible injury.
IMPORTANT ! : The TS525TU mount is designed to be
mounted to an 8" concrete, 8"x8"x16" concrete block, brick or
2" x 4" wood studs (16" on center).
--SAVE THESE INSTRUCTIONS!--
Installation Instructions TS525TU
3
DIMENSIONS
16.000
406.40
15
MAX
TILT
MAXIMUM WEIGHT CAPACITY = 125 lbs. (56.7 kg)
COLLAPSED
VIEW
200 X 200
SCREEN
CENTER
INCLUDED
PATTERNS
100 X 100
7.00" [177.8]
LEFT/RIGHT
ADJUSTMENT
9.277
.688
235.64
749.30
29.500
800
MAX. HORIZONTAL PATTERN
31.496
400
PATTERN
63.50
2.500
473.08
18.625
VERTICAL
8.33
.328
17.46
15.748
MAX.
.492
12.50
32.330
MAX. WIDTH
821.19
21.664
550.28
1.5
DISTANCE FROM WALL
WITH INTERFACE
[35.6]
1.4
WITHOUT INTERFACE
39.1
526.4
20.73
651.9
25.67
MAX EXTENSION
FROM WALL
