I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
This device complies with part 15 of the FCC rules. Operation is subject to the following 2 conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio or television
communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment to an outlet on a circuit other than that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
SL220
Suspended Ceiling Lift
SL220 Installation Instructions
2
DISCLAIMER
Milestone AV Technologies, and its affiliated corporations and
subsidiaries (collectively, "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
IMPORTANT SAFETY INSTRUCTIONS
WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING:FAILURE TO READ AND
FOLLOW THE FOLLOWING INSTRUCTIONS CAN RESULT
IN SERIOUS PERSONAL INJURY, DAMAGE TO EQUIPMENT
OR VOIDING OF FACTORY WARRANTY. Read these
instructions. Heed these instructions. Follow all instructions. It is
the installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
When using an electrical mounting system, basic precautions
should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS
PRODUCT!!!!
DANGER: TO REDUCE THE RISK OF
ELECTRIC SHOCK:
1. Always turn off power at source before cleaning.
2. Clean only with dry cloth.
CAUTION: Changes or modifications to this
unit not expressly approved by the manufacturer can void the
units FCC compliance rating and make the unit illegal to
operate.
WARNING: TO REDUCE THE RISK OF
BURNS, FIRE, ELECTRIC SHOCK, OR INJURY TO
PERSONS:
• Always turn off power at source before putting on or
taking off parts.
• Use this mounting system only for its intended use as
described in these instructions. Do NOT use
attachments not recommended by the manufacturer.
• Never operate this mounting system if it has a
damaged cord or plug. If it is not working properly
during testing, return the mounting system to a service
center for examination and repair.
• Keep the power cord away from heated surfaces.
• Never operate the mounting system with the air
openings blocked. Keep the air openings free of lint,
hair, and the like.
• Never drop or insert any object into any opening.
• Do not use outdoors unless marked for outdoor use. Do
not use this apparatus near water.
• Route cords and cables as shown in the installation
instructions.
• To disconnect, turn all controls to the off position, then
turn off power at source.
WARNING:RISK OF ELECTRIC SHOCK!
Connect this mounting system to a properly grounded outlet
only. See Grounding Instructions. Do not defeat the safety
purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding
plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
WARNING:Failure to provide adequate
structural strength for this component can result in serious
personal injury or damage to equipment! It is the installer’s
responsibility to make sure the structure to which this
component is attached can support five times the combined
weight of all equipment. Reinforce the structure as required
before installing the component.
WARNING:Exceeding the weight capacity
can result in serious personal injury or damage to equipment! It
is the installer’s responsibility to make sure the weight of all
components attached to the SL220 does not exceed 30 lbs
(13.6 kg).
WARNING:RISK OF INJURY! Do not place
video equipment such as televisions or computer monitors on
the ceiling pan of the SL220.
NOTE: This system has no user serviceable parts.
--SAVE THESE INSTRUCTIONS--
--KEEP THESE INSTRUCTIONS--
Installation Instructions SL220
3
TABLE OF CONTENTS
DISCLAIMER...................................................... 2
TABLE OF CONTENTS....................................... 3
TOOLS REQUIRED FOR INSTALLATION......... 4
PARTS................................................................ 4
LEGEND............................................................. 5
DIMENSIONS..................................................... 5
PREPARING FOR INSTALLATION.................... 6
Installation Requirements................................... 6
Power Requirements.......................................... 6
Preparing SL220 Framework.............................. 6
Installing SL220 Framework............................... 6
Securing SL220 Frame to Ceiling Structure....... 7
Solid Concrete Ceiling Structure................... 7
Steel Truss Ceiling Structure........................ 7
Wood Ceiling Structure................................. 8
Installing Cable to SL220 Frame......................... 8
Installing Junction Box and Outlet....................... 8
Electrical Rating.................................................. 9
Grounding Instructions........................................ 9
PREPARING THE SL220................................... 9
Removing Ceiling Pan........................................ 9
Installing IR Sensor and Power Cord.................. 9
Removing Projector Cradle (Optional).............. 10
PLACING SL220 INTO CEILING STRUCTURE. 11
Replacing Projector Cradle............................... 12
Installing RPA/RPM, Bracket and Projector...... 12
Adjustments...................................................... 13
Connecting Control Wiring................................ 13
Replacing Ceiling Pan....................................... 14
OPERATING MODES....................................... 14
Projector Shutdown Mode (Optional)................ 14
Current Sense Mode (Optional)........................ 14
Fault Condition.................................................. 15
RS485 Information............................................ 16
Remote Control Capabilities...............................17
Table 4: Wiring Table.........................................18
