I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
RMF2 RLF2
RXF2
Universal Fixed Mounts
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
RMF2/RLF2/RXF2
RMF2/RLF2/RXF2 Installation Instructions
2
DISCLAIMER
Milestone AV Technologies and its affiliated corporations and
subsidiaries (collectively "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
IMPORTANT WARNINGS AND
CAUTIONS!
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component. The wall to which the mount is being attached
may have a maximum drywall thickness of 5/8" (1.6cm).
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached does not exceed 125 lbs (56.7 kg)
for the RMF2 and RLF2 or 175 lbs (79.4 kg) for the RXF2.
Use with products heavier than the maximum weight
indicated may result in collapse of the mount and its
accessories causing possible injury.
DIMENSIONS - RMF2
7.00
WALL PLATE
OPENING
177.8
7.87
TOP MOUNTING
HOLE TO CENTERLINE
ARROW ON THE
WALL PLATE
200
2.50
CENTERLINE
TO BOTTOM OF
WALL PLATE
OPENING
63.5
11.00
279.4
MAX
[449]
17.68
22.00
558.8
15.75
MAX
400
16.50
419.1
-KICKSTAND LANYARDS
-WHEN KICKSTAND
IS ACTIVATED, THE
DISPLAY TILTS BACK 5
.79
(UP TO 1.54
USING SPACERS)
20.1
.28
HOLE SIZE
FOR LOCK
7.1
8.38
212.7
1.00
25.4
.34
8.7
WALL PLATE
OPENING
DETAIL A
ORIENTATION
AND CENTERLINE
NOTCHES
DETAIL B
SCALE 1 : 2
CENTERLINE
DIAMOND
Installation Instructions RMF2/RLF2/RXF2
3
DIMENSIONS - RLF2
DIMENSIONS - RXF2
7.00
WALL PLATE
OPENING
177.8
7.87
TOP MOUNTING
HOLE TO CENTERLINE
ARROW ON THE
WALL PLATE
200
2.50
CENTERLINE
TO BOTTOM OF
WALL PLATE
OPENING
63.5
15.38
390.5
MAX
[670]
26.38
30.75
781.1
15.75
MAX
400
16.50
419.1
-KICKSTAND LANYARDS
-WHEN KICKSTAND
IS ACTIVATED, THE
DISPLAY TILTS BACK 5
.79
(UP TO 1.54
USING SPACERS)
20.1
.28
HOLE SIZE
FOR LOCK
7.1
8.38
212.7
1.00
25.4
.34
8.7
WALL PLATE
OPENING
DETAIL A
SCALE 1 : 2
ORIENTATION
AND CENTERLINE
NOTCHES
DETAIL B
SCALE 1 : 2
CENTERLINE
DIAMOND
7.00
WALL PLATE
OPENING
177.8
7.87
TOP MOUNTING
HOLE TO CENTERLINE
ARROW ON THE
WALL PLATE
200
2.50
CENTERLINE
TO BOTTOM OF
WALL PLATE
OPENING
63.5
19.00
482.6
MAX
[965.2]
38.00
38.00
965.2
19.69
MAX
500
-KICKSTAND LANYARDS
-WHEN KICKSTAND
IS ACTIVATED, THE
DISPLAY TILTS BACK 5
.79
(UP TO 1.54
USING SPACERS)
20.1
.28
HOLE SIZE
FOR LOCK
7.1
8.38
212.7
1.00
25.4
.34
8.7
WALL PLATE
OPENING
DETAIL A
SCALE 1 : 2
ORIENTATION
AND CENTERLINE
NOTCHES
DETAIL B
SCALE 1 : 2
CENTERLINE
DIAMOND
