Specicaons & appearance subject to change
Contact: 1-800-4GIBSON -800-444-2766) (1
Cerwin-Vega! A member of the Gibson family of brands
Cerwin-Vega! P-Series
PORTABLE POWERED LOUDSPEAKERS PRODUCT OVERVIEW
The Cerwin-Vega! P-Series is a powerful, portable speaker
system with legendary Cerwin-Vega! performance. The P-
Series combines rugged construcon, extreme clarity and
unmatched bass performance in an easy to use and
versale package. The P-Series family includes two active
speaker products: the P1500X full-range speaker and the
P1800SX subwoofer. Both are suited for any sound
reinforcement applicaon, from live performances to DJ
gigs, as well as public speaking engagements .
The P1500X is a two-way, bi-amped, full-range bass-reex
speaker. It employs a 15-inch woofer and high-frequency a
compression driver, powered by a custom Class-D
amplier. With a power rang of 1500 was, the P1500X
is the most powerful PA product in its class. A proprietary
hemi-conical horn provides premium sound clarity over an
even and wide coverage area. A built-in mixer with
convenient I/O connecons allows for simple and fast
setup, while enhanced EQ, VEGA BASS boost and high-pass
lters enable exact tuning and exceponal performance
for any applicaon. The P1500X is a versale product that
can be used as a single speaker for a small venue, set in
pairs for a larger venue needing more coverage and SPL, or
as a oor monitor for a band.
To add value and versality for traveling bands or permanent installs, the P1500X enclosure is built of a
lightweight, robust polymer featuring integrated ribs for durability and resonant free performance. The
professional enclosure includes a unique mul-angle pole cup, comfortable ergonomic handles and built-in
rigging points on the P1500X for suspended installaons .
The P1800SX complements the P-Series with low frequency extension. The powered subwoofer employs an
18-inch woofer with a custom 2000 wa Class-D amplier. The large woofer and matched amplier are
enclosed in a mul-ply hardwood cabinet, the combinaon which provides a superior punch and extreme low-
frequency response, which are both Cerwin-Vega! trademarks. Like the P1500X, the P1800SX has frequency-
shaping controls and the unrivaled VEGA BASS boost. This ensures the user can dial in the correct amount of
bass for each venue. While designed for use with the P1500X, the P1800SX can also be used for low frequency
extension with other Cerwin-Vega! tops or even other brands. Addionally, the THRU, MIX and LINK outputs
allow for system expandability and fast daisy-chaining between components.
Experience POWER and PUNCH that only the new Cerwin-Vega! P-Series System can deliver.
Specicaons & appearance subject to change
Contact: 1-800-4GIBSON -800-444-2766) (1
Cerwin-Vega! A member of the Gibson family of brands
Cerwin-Vega! P-Series
PORTABLE POWERED LOUDSPEAKERS
FEATURES/BENEFITS
Fully integrated sound reinforcement system results in a simplied soluon to delivering public address,
entertainment and performance monitoring
Rugged enclosure with mulple handle locaons makes transport and setup safe and easy
Full-range and subwoofer models use high eciency Cerwin-Vega! components for low-frequency bass with punch
The integrated mixer and ecient amplier design reduces the amount of gear required for an easier setup and less
worry about limited power resources
Angle-adjustable pole mount socket, side-wedge shaped enclosure and M10-threaded suspension points support a
variety of permanent and portable setups
Stackable design to minimize transportaon and storage area. Thick, powdered coated grill protects the drivers during
transportaon and storage
Caster are included with the P1800SX subwoofer for easy transfer to
and from the performance area
MIXER
Built-in 3-channel mixer with easy to idenfy controls, and intuive
layout for fast setup and minimal connecons
THRU, MIX or LINK -outputs for fast ‘daisy chain’ connecons and
system expandability
User controlled digital lters and ENHANCED EQ allow the system to
be tuned to the exact requirements of the event
AMPLIFIER
P1500X - 1500 wa Bi-amplied Class-D design and universal
switching mode power supply delivers premium performance in an
ecient and portable design
The P1800SX subwoofer contains a 2000 wa Class- amplier design D
capable of delivering superior low-frequency punch
Built-in limiter with on/o LED indicator provides essenal protecon
to minimize the risk of down-me and prevent component damage
SPEAKER
Proprietary Cerwin- ga! Hemi-Conical Waveguide provides smooth Ve
on and o axis frequency response
High Frequency Driver compression driver provides natural sounding –
instruments and vocals
Low Frequency Driver Metal frame, reex loaded woofers achieve –
accurate bass response and provides the punch you expect from a
Cerwin-Vega! system
Direct-ring subwoofer features internal bracing to reduce enclosure
resonance and increase transient performance
Specicaons & appearance subject to change
Contact: 1-800-4GIBSON -800-444-2766) (1
Cerwin-Vega! A member of the Gibson family of brands
PRODUCT OVERVIEW
USABILITY
Angle-adjustable pole mount socket, side-wedge shaped enclosure and M10-threaded suspension points support a
variety of permanent and portable setups
The pole mount socket can be angle adjusted to set the
loudspeaker in a normal at posion or a 7.5 degree
downward lt for improved audience coverage from a
raised posion
An integrated rigid feet design on the side-wedge
shaped enclosure provides the ability to use the P1500X
in a oor monitor conguraon
Suspended applicaons using M10 threaded
points are conveniently built-in for vercal and
horizontal orientaon
Floor Monitor
Pole Flat or Tilt
Suspension
