Digital Camera

User’s Guide

Thank you for purchasing this CASIO product.

• Before using it, be sure to read the precautions contained in this User’s Guide.

• Keep the User’s Guide in a safe place for future reference.

• For the most up-to-date information about this product, visit the official EXILIM Website

at http://www.exilim.com/

This manual covers the firmware versions below.

Camera: Ver. 2.01 Controller: Ver. 2.00

As you unpack your camera, check to make sure that all accessories shown below

are included. If anything is missing, contact your original retailer.

*The shape of the power cord plug varies according to the country or geographic

area where the camera is sold.

Accessories

Camera

(EX-FR100)

Controller

(EX-FR100CT)

Hinge Unit

• Comes pre-attached to

the camera.

Tripod nut Carabiner strap USB-AC adaptor

(AD-C53U)

Power cord*Micro USB cable Basic Reference

• The contents of this manual are subject to change without notice.

• The contents of this manual have been checked at each step of the production

process. Feel free to contact us if you notice anything that is questionable,

erroneous, etc.

• Any copying of the contents of this User’s Guide, either in part or its entirety, is

forbidden. Except for your own personal use, any other use of the contents of this

manual without the permission of CASIO COMPUTER CO., LTD. is forbidden

under copyright laws.

• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost

profits suffered by you or any third party due to the use or malfunction of this

product.

• CASIO COMPUTER CO., LTD. shall not be held liable for any damages, lost

profits, or claims by third parties arising out of the use of the EXILIM Connect

application software.

• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost

profits caused by loss of memory contents due to malfunction, repair, or any other

reason.

• Note that the example screens and product illustrations shown in this User’s Guide

may differ somewhat from the screens and configuration of the actual camera.

LCD Panel

The liquid crystal panel of the monitor screen uses high-precision technology that

provides a pixel yield in ex that some very small number cess of 99.99%. This means

of pixels may not light or may remain lit at all times. This is due to the characteristics

of the liquid crystal panel, and does not indicate malfunction.

Read this first!

Charge batteries before use.

The camera and the controller each have a built-in rechargeable lithium ion

battery. The batteries are not charged when you purchase the camera, so you will

need to charge both the camera and controller before using them.

Take test shots

Before shooting your final image, shoot a test shot to ensure that the camera is

recording correctly.

4Contents

Contents

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Monitor Screen Contents and How to Change Them . . . . . . . . . . . . . . . . . . . . 9

Quick Start Basics 12

What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Using the Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Hinge Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Tripod nut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Carabiner Strap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Using the Touch Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Turning Power On and Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 29

Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

To Shoot a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Recording Images 40

To configure REC mode settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Selecting a Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Shooting a Burst of Images . . . . . . . . . . . . . . . . . . . . . . . (High Speed CS). . . 42

Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Art Shot). . . 43

Shooting Scenes of an Activity at a Fixed Interval . . . . (Interval Shooting) . . 44

Shooting with Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

5Contents

Advanced Recording Settings 52

Using the REC Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Make-up). . . 53

Shooting by Touching the Monitor Screen . . . . . . . . . . . . (Touch Shooting). . . 53

Reducing Blur Due to Camera Movement During

Movie Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Movie Anti Shake). . . 54

Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Image Size). . . 55

Movie Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . . (Movie Quality). . . 56

Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . (Brightness). . . 56

Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance). . . 57

Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(ISO). . . 58

Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus). . . 59

Self-shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Mirror Image) . . . 60

Reducing Wind Noise during Movie Recording . . . . . . . . (Wind Noise Cut) . . . 60

Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review). . . 61

Displaying a Grid on the Monitor Screen . . . . . . . . . . . . . . . . . . . . . . (Grid). . . 61

Viewing Snapshots and Movies 62

Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Viewing the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Creating a Movie of a Day’s Images . . . . . . . . . . . . . . . . (Highlight Movie) . . 64

Creating a Collage of a Day’s Snapshots . . . . . . . . . . . . (Highlight Photo) . . 66

Changing the Highlight Score of an Image . . . . . . . . . . . (Highlight Score) . . 67

Creating a Time Lapse Movie . . . . . . . . . . . . . . . . . . . . . . . . (Time Lapse) . . 68

Other Playback Functions (PLAY) 70

Using the PLAY Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Rotation). . . 71

Connecting the Camera with a Smartphone

(Wireless Connection) 72

Controlling Your Camera with a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . 72

Using a Wireless Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Getting Ready to Establish a Connection between a Smartphone and Your

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Installing the EXILIM Connect App on Your Smartphone . . . . . . . . . . . . . . . . . . 75

Establishing a Wireless Connection for the First Time . . . . . . . . . . . . . . . . . . . . 76

Using a Smartphone as a Camera Remote Controller (Shoot with phone) . . 79

Sending a Snapshot or Movie File from Camera Memory

to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . (Send Selected Image) . . 80

Viewing Snapshots and Movies in Camera Memory

on a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (View on phone) . . 81

6Contents

Configuring Wireless Connection Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Having Images Shot with the Camera Sent

to a Smartphone Automatically . . . . . . . . . . . . . . . . . . . . . . . . (Auto Send) . . . 82

Specifying Images to be Sent by Auto Send . . . . (Auto Send File Settings) . . . 83

Resizing Snapshots before Sending Them

to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize When Sending) . . . 84

Changing the Camera Password

for Wireless LAN Connection . . . . . . . . . . . . . . . . . . . . . (WLAN password). . . 84

Unpairing the Camera from a Smartphone . . . . . . . . . . . . . . . . (Unpairing). . . 85

Using Two Cameras at the Same Time

(Multi Camera Mode) 86

What you can do with two cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Preparing a Second Camera to be Registered on the Controller . . . . . . . . . . 87

Registering a Second Camera on the Controller . . . . . . . . . . . . . . . . . . . . . . . 87

Multi Camera Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Shooting with the Multi Camera Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Shooting with the Multi Image Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Shooting with the Single Image Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Viewing Snapshots and Movies in the Multi Camera Mode. . . . . . . . . . . . . . . 97

Multi Image Screen Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Single Image Screen Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Printing 100

Printing with a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Using the Camera with a Computer 101

Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . 101

Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . 105

Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Other Settings (Set Up) 111

Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . .(Screen) . .111

Selecting Display Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Info) . .111

Locking the Camera or Controller Screen Orientation . . . (Rotation Lock) . 112

Configuring Camera Sound Settings . . . . . . . . . . . . . . . (Camera Sound) . 112

Using the Vibration Function . . . . . . . . . . . . . . . . . . . . . . . . . . . (Vibration) . 113

Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 113

Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 114

Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 114

Specifying the Controller Sleep State Trigger Time . . . . . . . . . . . . (Sleep) . 114

7Contents

Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . . (Format) . 115

Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . . (Reset) . 115

Checking the Current Camera Firmware Version . . . . . . . . . . . . (Version) . 116

Registering a Second Camera . . . . . . . . . . . . . . . . . . . . . . (Multi-Pairing) . 116

Appendix 117

Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Shock resistant, Splashproof, Dustproof . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Disposing of the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . . 155

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

The numbers in parentheses indicate the pages where each item is explained.

General Guide

cmcnco cp

6789

21 3

bk bl bm

Camera

Wireless LAN connection

lamp (page 77)

Operation lamp

(pages 21, 24)

[p] (Power) (page 27)

Memory card slot

(page 32)

[RESET] button

(page 149)

[CARD] cover (page 32)

Speaker

Lens (page 18)

Microphone

(pages 18, 51)

Shutter button (page 35)

[0] (Movie) (page 49)

[FREE] lever (page 16)

[USB] port

(pages 20, 23)

[USB] cover

(pages 20, 23)

Strap holes

Controller

[USB] cover

(pages 20, 23)

[RELEASE] button

(page 15)

[RESET] button

(page 149)

[USB] port

(pages 20, 23)

Carabiner strap

attachment bar

(page 18)

Strap holes

[0] (Movie) (page 49)

Shutter button

(page 35)

Operation lamp

(pages 21, 24)

[p] (Power) (page 27)

Hinge unit slot

(page 15)

Camera Controller

The monitor screen uses various indicators, icons, and values to keep you informed

of the camera’s status.

• The sample screens in this section are intended to show you the locations of all the

indicators and figures that can appear on the monitor screen in various modes.

They do not represent screens that actually appear on the camera.

.Snapshot Recording

Monitor Screen Contents and How to Change Them

1 2 4 65 7 8

White Balance (page 57)

Focus mode (page 59)

Digital zoom (page 48)

Auto Send (page 82)

Remaining movie memory capacity

(page 155)

Remaining snapshot memory

capacity (page 155)

Snapshot image size (page 55)

Movie quality (pages 49, 56)

Touch Shooting function (page 53)

Movie Anti Shake (page 54)

ISO sensitivity (page 58)

Brightness (page 56)

Date/Time (pages 29, 113)

Camera battery level indicator

(page 26)

Controller battery level indicator

(page 26)

Communication status between

camera and controller (page 27)

PLAY mode icon (page 29)

“ ” (Show Icons) icon

Interval Shooting icon (page 44)

Wireless mode icon (page 74)

Recording mode icon (page 41)

Menu icon (page 52)

.Movie Recording

NOTE

• If you do not perform any operation for about three seconds during snapshot

recording or movie recording, icons will become transparent.

.Snapshot Viewing

Focus mode (page 59)



Movie quality (

pages 49, 56)

Movie recording time (page 50)

21 3

543 6

bqbr bp bo

Current image number/total number of

grouped images (pages 42, 44)

Group images

(High Speed CS (page 42),

Interval Shooting (page 44))

Auto Send (page 82)

Protect indicator

Folder name-file name (page 108)

Snapshot image size (page 55)

Highlight Score (page 67)

Make-up (page 53)

White Balance (page 57)

ISO sensitivity (page 58)

Brightness (page 56)

Shutter speed



Image menu icon (p

age 63)

Camera battery level indicator

(page 26)

Controller battery level indicator

(page 26)

Date/time (pages 29, 113)

Communication status between

camera and controller (page 27)

“ ” (Show Icons) icon

REC mode icon (page 29)

Delete icon (page 38)

Wireless mode icon (pages 74, 81)

Edit icon (pages 64, 66, 67, 68)

Menu icon (page 70)

NOTE

• The folder name and file name in the upper right corner of the monitor screen has

the meaning described below (page 108).

Example: 100-0023: 23rd image file in the folder named “100CASIO”.

.Movie Playback

NOTE

• If you do not perform any operation for about three seconds during snapshot

viewing or movie playback, icons will become transparent.

Movie recording time (page 62)

Movie quality (pages 49, 56)

Highlight Score (page 67)



Image menu ico

n (page 63)

Date/time (pages 29, 113)

“ ”

Movie play ico

n (page 62)

“ ” (Show Icons) icon

1 2

12 Quick Start Basics

Quick Start Basics

Your CASIO camera is packed with a powerful selection of features and functions to

make recording of digital images easier, including the following main functions.

.Shooting

What you can do with your CASIO camera

A variety of shooting styles

The camera connects to the controller using Bluetooth

wireless technology (Bluetooth).

The hinge unit and tripod nut make it possible to shoot from a

variety of different angles. The camera can also be rotated 90

degrees, which means you can change the orientation of a

snapshot with little physical repositioning of the camera.

Interval Shooting

Shoot snapshots and/or movies at fixed intervals. It’s a

great way to chronicle an activities or changes over

time.

Art Shot

A variety of artistic effects help to make even common,

ordinary subjects become more novel and exciting.

*See page 15 for more information.

*See page 44 for more information.

*See page 43 for more information.

13 Quick Start Basics

.Viewing

.Sharing

Highlight Photo

You can configure camera settings to automatically

select snapshot highlights and generate a collage of

them.

Highlight Movie

You can configure camera settings to automatically

select snapshot and movie highlights, and create a

movie of them.

Time Lapse

Creates a movie of snapshots you shot.

Wireless Connection

Turns your smartphone into a camera remote

controller and allows you to select one or more

snapshot and/or movie file in camera memory and

send a copy to a smartphone.

*See page 66 for more information.

*See page 64 for more information.

*See page 68 for more information.

*See page 72 for more information.

14 Quick Start Basics

.Simultaneous Use of Two Cameras

Multi Camera Mode

You can register two cameras on the controller and

operate them both at the same time or individually.

*See page 86 for more information.

15 Quick Start Basics

You can configure the camera to suit your specific needs by attaching the hinge unit,

which enables attachment of the controller, and other included and optionally

available attachments. This way you can configure the camera to suit your specific

needs.

IMPORTANT!

• Do not apply strong pressure to the surface of the monitor screen. Doing so can

damage it.

• Never touch the lens with your fingers. Finger smudges, dirt, and other foreign

matter on the lens can interfere with proper operation of the camera. Use a blower

or other means to keep the lens and flash window free of dirt and dust, and wipe

gently with a soft, dry cloth.

You can attach the controller to the camera and use the camera as a normal camera.

.To attach the controller

1. With the camera lens pointed in the

same direction as the controller’s

monitor screen, slide the hinge unit into

the controller’s hinge unit slot.

2. Push the hinge unit in until you hear it

click into place.

.To detach the controller

1. While holding down the controller’s

[RELEASE] button, pull it out of the

camera.

Using the Attachment

Controller

Hinge unit slot

Align the 2 mark on the end of

the hinge unit with the 8 mark

next to the hinge unit slot.

[RELEASE] button

16 Quick Start Basics

.To use the hinge unit as a stand

.To change the shooting direction by 90 degrees

1. While pulling down on the camera’s [FREE]

lever, rotate the camera clockwise 90 degrees

until you hear a click.

• Align the camera’s operation lamp with the C

mark on the hinge unit.

• The indentations in the lens ring indicate the

orientation of the long dimension of the image

being shot.

.To remove the hinge unit from the camera

1. While pulling down on the camera’s [FREE]

lever, rotate the camera counterclockwise

about 15 degrees until its operation lamp is

aligned with the A mark on the hinge unit.

Hinge Unit

Lens ring

[FREE] lever

Indentations

A B C

[FREE] lever

18 Quick Start Basics

1. Pass the carabiner strap belt around

the controller’s carabiner strap

attachment bar.

2. Pass the belt through the buckle to

secure it.

Pull on the belt until the belt flap is passed

all the way through the buckle.

3. Hook the flap on the buckle.

4. Pull on the carabiner and controller to confirm that

the flap is hooked on the buckle and is secure.

IMPORTANT!

• The carabiner strap is not intended for mountain climbing use. It is designed only to

support the camera.

NOTE

• When shooting hold the camera still. Carefully press the shutter button and take

care to avoid all movement as the shutter releases and for a few moments after it

releases.

• Take care that your fingers and the strap do not cover

any of the areas indicated in the illustration.

• Never swing the camera around by its strap.

• The supplied strap is intended for use with this

camera only. Never use it for any other purpose.

Carabiner Strap

flap

Microphone

Lens

19 Quick Start Basics

The monitor screen of the camera is a touch panel.

This means you can perform the following operations

by touching the screen with your fingers.

Touch

Momentarily touching the screen with your finger.

Touch the screen to select an icon or menu item, and

to configure settings.

Flick

Holding your finger against the screen as you flick it

up, down, left, or right.

Use flick to scroll forward through images.

Spread

Holding your thumb and forefinger against the screen

as you spread them out.

Use spread to enlarge the screen image.

Squeeze

Holding your thumb and forefinger against the screen

as you bring them together.

Use squeeze to reduce the size of the screen image,

and to display multiple images.

IMPORTANT!

• Never use a pointed or hard object to perform screen operations. Doing so can

damage the screen.

• The camera will have a hard time interpreting a screen operation made using your

fingernails. Use the fleshy pad of your finger.

Using the Touch Panel

Monitor Screen

20 Quick Start Basics

NOTE

• Applying a commercially available LCD protective sheet will reduce the operation

sensitivity of the monitor screen.

The camera and the controller each have a built-in rechargeable lithium ion battery.

The batteries are not charged when you purchase the camera, so you will need to

charge both the camera and controller before using them.

You can use either of the two following methods to charge the batteries.

• USB-AC adaptor

• USB connection to a computer (Using the included micro USB cable.)

.To charge with the USB-AC adaptor

While the camera and controller are turned off, connect in the sequence shown

below.

• When disconnecting the USB-AC adaptor from the camera or controller, be sure to

disconnect from them first.

First, charge the battery prior to use.

Charging time : Camera: Approximately 2 hours 15 minutes

Controller: Approximately 2 hours 55 minutes

USB-AC adaptor

(AD-C53U)

When plugging in the connectors, orient this marking as described below.

Camera : Towards the lens side

Controller : Towards the monitor screen side

[USB] port

Micro USB cable

(included with camera)

Power cord

[USB] cover

21 Quick Start Basics

NOTE

• If you turn on the camera or controller while charging with the USB-AC adaptor,

you will be able to perform normal recording operations. In this case, however,

charging of the camera will be stopped while it is turned on.

.Operation Lamp Indications

While power is off

While power is on

• Camera

• Controller

Operation Lamp Status Meaning

Lit red Charging

Flashing red

Charging stopped due to abnormal internal

temperature, USB-AC adaptor problem, battery

problem (page 141), timer operation.

Unlit Charging complete

Operation Lamp

Status Meaning

Lit green Camera turned

on Charging stopped

Slow red-amber

flashing

In sleep state

Charging

High speed red-green

flashing

Charging stopped due to abnormal

internal temperature, USB-AC adaptor

problem, battery problem (page 141),

timer operation.

Slow green flashing Charging complete

Operation Lamp Status Meaning

Lit red Charging

Slow red-amber flashing Charging (sleep state)

High-speed green-amber

flashing

Charging stopped due to abnormal internal

temperature, USB-AC adaptor problem, battery

problem (page 141), timer operation.

High-speed red-green flashing Same as above (sleep state)

Lit green Charging complete

Slow green flashing Charging complete (sleep state)

22 Quick Start Basics

IMPORTANT!

• A battery that has not been used for a long time and/or ambient temperature can

cause charging to take longer than normal. These conditions may also cause the

operation lamp to flash red. If this happens, refer to page 141.

• The USB-AC adaptor will become warm during charging. This is normal and does

not indicate malfunction.

• The shape of the power plug depends on each country or geographic area.

If the operation lamp is not lit or flashing during charging, check the orientation of the

USB cable connectors.

• Make sure that you insert the cable connector into the USB port until you feel it

click securely into place. Failure to insert the connector fully can result in poor

communication or malfunction.

• Note that even while the connector is fully inserted, you

still will be able to see the metal part of the connector

as shown in the illustration.

Camera

Controller

23 Quick Start Basics

.To charge using a USB connection to a computer

While the camera and controller are turned off, connect in the sequence shown below

(, ).

• If the camera or controller is on, hold down [p] (Power) for about two seconds to

turn it off before connecting to the computer.

NOTE

• If you turn on the camera while charging over a USB connection to a computer is in

progress, the camera will establish a USB connection with the computer. Charging

will continue. Charging will also continue if you turn on the controller. Note that

certain types of computers or connection environments may stop charging if supply

power is low.

Charging time: Camera: Approximately 2 hours 55 minutes

Controller: Approximately 2 hours 55 minutes

USB

Micro USB cable

(included with camera)

[USB] port

USB port

Computer

(power turned on)

When plugging in the connectors, orient this marking as described below.

Camera : Towards the lens side

Controller: Towards the monitor screen side

[USB] cover

24 Quick Start Basics

.Operation Lamp Indications

While power is off

While power is on

• Camera

• Controller

Operation Lamp Status Meaning

Lit red Charging

Flashing red

Charging stopped due to abnormal internal

temperature, USB-AC adaptor problem, battery

problem (page 141), timer operation.

Unlit Charging complete

Operation Lamp Status Meaning

Lit amber Charging

High speed red-green flashing

Charging stopped due to abnormal internal

temperature, USB-AC adaptor problem, battery

problem (page 141), timer operation.

Lit green Charging complete

Operation Lamp Status Meaning

Lit amber Charging

Slow red-amber flashing Charging (sleep state)

High-speed green-amber

flashing

Charging stopped due to abnormal internal

temperature, USB-AC adaptor problem, battery

problem (page 141), timer operation.

High-speed red-green flashing Same as above (sleep state)

Lit green Charging complete

Slow green flashing Charging complete (sleep state)

25 Quick Start Basics

IMPORTANT!

• The first time you connect the camera or controller to your computer with the USB

cable, an error message may appear on your computer. If this happens, disconnect

and then reconnect the USB cable.

• A battery that has not been used for a long time, certain types of computers, and

connection conditions can cause charging to take longer than normal. These

conditions may also cause the operation lamp to flash red. If this happens, refer to

page 149.

• For faster charging, use of the supplied USB-AC adaptor is recommended.

• Charging is not performed while the connected computer is in the hibernate mode.

Other Charging Precautions

• With the two charging methods described above, you can charge the batteries.

Never use any other type of charger device. Attempting to use a different charger

can result in unexpected accident.

• This model can be charged only via from USB 2.0 specification USB port.

• USB charging devices and power supply devices are subject to fixed standards.

Use of an inferior device or a device that is not up to standard can cause

malfunction and/or failure of your camera.

• Operation is not guaranteed in the case of a computer built or modified by you.

Even in the case of a commercially available computer, certain USB port

specifications may make it impossible to charge via the USB cable.

• A battery that is still warm immediately after normal use may not charge fully. Give

the battery time to cool before charging it.

• A battery discharges slightly while it is loaded in the camera or controller. Because

of this, it is recommended that you charge the battery immediately before you need

to use it.

• Charging the battery may cause interference with TV and radio reception. If this

happens, plug the USB-AC adaptor into an outlet that is further away from the TV

or radio.

• Actual charging time depends on current battery capacity and charging conditions.

• Do not use the USB-AC adaptor with any other device.

• Never use the power cord with another device.

• Use only the USB-AC adaptor and USB cable specified in this manual for charging.

Use of any other type of devices may result in improper charging.

26 Quick Start Basics

Checking the Current Battery Level

As battery power is consumed, a battery indicator on the monitor screen indicates its

current level as shown below.

indicates battery power is low. Charge the battery as soon as possible.

indicates that the battery is about to go dead. Charge the battery immediately.

• The level shown by the battery indicator may change when you switch between the

REC mode and PLAY mode.

• Leaving the camera for about 8 days with no power supplied while the battery is

dead will cause its date and time settings to be cleared. A message telling you to

configure time and date settings will appear the next time you turn on the camera

after restoring power. When this happens, configure date and time settings (page

113).

• See page 159 for information about battery life and number of shots.

Level High Low

Battery

Indicator

Camera ***

Controller ***

Indicator Color White White* * Red *Red

27 Quick Start Basics

.Camera-Controller Wireless Connection

The camera and controller communicate over a

Bluetooth wireless technology connection. Once

you perform the “pairing” operation required for

Bluetooth wireless technology connection, the

camera and controller will automatically connect to each other whenever you turn

them on. Note that the connection will be lost when the distance between the camera

and controller becomes too great. The controller will turn off after a preset amount of

time after the Bluetooth wireless technology connection is lost. The camera will

remain on, so you can shoot images by pressing its shutter button.

IMPORTANT!

• Your camera has Bluetooth wireless technology communication functionality built

in. Avoid operating the camera (including camera standalone operations) inside of

aircraft or anywhere else where wireless data communication is restricted.

.To turn on power

Both the camera and controller need to be turned on in order to use them.

• Turning on the camera causes the camera and controller operation lamps to light

green, and automatically starts an operation to establish a Bluetooth wireless

technology connection between the camera and controller. An image appears on

the controller and shooting is enabled.

• The connection between the camera and controller is affected by their orientation

and by the distance between them.

• The maximum range for shooting with the controller’s shutter button is around

10 meters (32.8'). The maximum range for viewing the image on the controller’s

monitor screen is around five meters (16.4').

• If the connection is poor, the controller operation lamp will flash green and

“ ” (Communication status between camera and controller) will appear on the

monitor screen. Camera response may be slow if you perform an operation on the

controller while communication conditions are bad. If this happens, try adjusting the

orientation and the distance between the camera and controller.

Turning Power On and Off

Camera

Press [p] (Power).

Controller

Press [p] (Power).

[p] (Power)

Operation lamp

[p] (Power)

Operation lamp

28 Quick Start Basics

• Note the precautions below to ensure stable

communication between the camera and

controller.

– Make sure nothing is blocking the gray areas

as shown in the illustrations.

– Point the back of the controller at the

camera.

– Make sure there are no obstacles in the path

between the camera and controller.

Sleep Mode

If you press [p] (Power) on the controller or if you do not perform any controller

operation for the time specified by the “Sleep” setting on the Setup menu (page 114)

while there is a Bluetooth wireless technology connection between the camera and

controller, the camera and controller will enter a sleep state. The operation lamp

slowly flashes green while the camera is in the sleep mode. To restore the controller

display, press any controller button. A low-power Bluetooth wireless technology

connection between the camera and controller is maintained even while they are in

the sleep mode, so operation is quickly enabled when you are ready to use the

camera and controller.

• If the distance between the camera and controller becomes to great or if

communication conditions become bad while the camera is in the sleep mode, the

connection may be dropped between them.

29 Quick Start Basics

Toggling Between the REC Mode and PLAY Mode

.To turn off power

On both the camera and the controller, hold down [p] (Power) for about two

seconds.

• Turning off the camera will cause the controller to turn off automatically.

• The camera will emit a sound when the camera is turned off. The camera turns off

when the power down process is complete.

The first time you turn on the camera, a screen appears for configuring the display

language, date, and time settings. Failure to set the date and time correctly will cause

the wrong date and time data to be recorded with images.

IMPORTANT!

• Camera models sold in certain geographic areas may not support display language

selection.

1. Turn on the camera and controller (page 27).

• If this is the first time you are turning on power, a language selection screen will

appear. If the screen does not appear, check to make sure that the camera is

turned on.

2. Flick (page 19) the controller screen upwards and downwards or touch

“ ”, “ ” until you find the language you want, and then touch to

select it.

To enter the

PLAY mode

In the REC mode, touch “ ” (PLAY).

• If “ ” (PLAY) is not displayed on

the screen, you can touching the

Review image (page 61), or switch

to the PLAY mode by touching

“ ” (Show Icons) and then

touching “ ” (PLAY).

To enter the

REC mode

In the PLAY mode, touch “ ”

(Show Icons). On the screen image

that appears, touch “ ” (REC).

Configuring Basic Settings the First Time You Turn On the

Camera

“ ”

(Show Icons)

Screen after “ ”

(Show Icons) is touched

“ ” (PLAY) / “ ” (REC)

30 Quick Start Basics

3. Touch the date display format you want.

Example: July 10, 2017

YY/MM/DD * 17/7/10

DD/MM/YY * 10/7/17

MM/DD/YY * 7/10/17

4. Set the date and the time.

• Touch the value you want to change (year,

month, day, hour, minute) and then touch “ ”,

“ ” to change it.

• To switch between 12-hour and 24-hour format,

select “am (pm)”/“24h” and then touch “ ”, “ ”

to change the setting.

5. When the date and time settings are the way

you want, touch “OK”.

NOTE

• Each country controls its local time offset and the use of summer time, and so they

are subject to change.

• While the camera is connected to a smartphone with the EXILIM Connect app, you

can execute auto date and time adjustment. The camera’s time zone will be

changed automatically in accordance with the smartphone’s time zone. For details,

see the EXILIM Connect User’s Guide (page 74).

If you make a mistake configuring display language, date, or time settings with the

above procedure, refer to the following pages for information about how to correct

the settings.

– Display language: Page 114

– Date and time: Page 113

12/24 hour switch icon

31 Quick Start Basics

Though the camera has built-in memory that can be used to store images and

movies, you probably will want to purchase a commercially available memory card for

greater capacity. The camera does not come with a memory card. Images recorded

while a memory card is loaded are saved to the memory card. When no memory card

is loaded, images are saved to built-in memory.

• Snapshots and movies stored in built-in memory cannot be copied to a memory

card.

• For information about memory capacities, see page 155.

– microSD Memory Card

– microSDHC Memory Card

– microSDXC Memory Card

• The above are supported memory card types as of June 2016.

• This camera supports use of microSD memory cards of the

following types and capacities: microSD memory cards up to 2GB; microSDHC

memory cards greater than 2GB, up to 32GB; microSDXC memory cards greater

than 32GB, up to 2TB. Note that the ability to use any particular card with this

camera, even if it satisfies the above capacity and type requirements, is not

guaranteed.

. Memory Card Handling Precautions

Certain types of memory cards can slow down processing speeds. In particular, high-

quality movies may not be able to be stored correctly. A slow memory card can take

too much time to record data and result in breaks in the image and/or audio during

playback.

Preparing a Memory Card

Supported Memory Cards

Warning!

0 Memory cards are small and present a risk of accidentally being swallowed

by infants and young children. Keep memory cards out of the reach of

infants and young children. If a memory card is ever swallowed accidentally,

contact a physician immediately.

32 Quick Start Basics

1. On the camera, hold down [p]

(Power) for about two seconds to

turn off power, and then open the

[CARD] cover.

2. Load a memory card.

Positioning the memory card so its back

is facing upwards (towards the lens side

of the camera), slide it into the card slot

all the way in until you hear it click

securely into place.

3. Close the [CARD] cover.

IMPORTANT!

• Never insert anything besides a supported memory card (page 31) into the memory

card slot.

• Should water or any foreign object ever get into the card slot, immediately turn off

the camera, and contact your retailer or nearest CASIO authorized service center.

To load a memory card

Back

Front Back

33 Quick Start Basics

. To replace the memory card

Press the memory card and then release it.

This will cause it to pop out of the memory

card slot slightly. Pull the card out the rest of

the way and then insert another one.

• Turn off the camera before replacing the

memory card. Replacing the card while

the camera is on can result in recorded

images not being saved and even damage

the memory card.

Format a memory card on the camera before using it for the first time.

IMPORTANT!

• Formatting a memory card that already has snapshots or other files on it, will delete

its contents. Normally you do not need to format a memory card again. However, if

storing to a card has slowed down or if you notice any other abnormality, re-format

the card.

• Be sure to use the camera to format a memory card. Formatting a card on a

computer will result in a non-SD standard format, which can greatly slow down

processing time and cause compatibility, performance, and other problems.

1. Load a memory card (page 32).

2. Turn on the camera and controller, and then touch “ ” (Show

Icons).

3. Touch “MENU”.

4. Touch the “¥ Setup” tab.

5. Flick upwards and downwards until you find “Format”, and then touch

it.

6. Touch “Format” and then touch “Yes”.

This starts the memory card format operation.

To format (initialize) a new memory card

34 Quick Start Basics

Your camera has a variety of different recording modes to suit various shooting

conditions and objectives (page 41). This section explains general shooting

procedures using the auto recording mode.

You can select one of two auto recording modes (Auto or Premium Auto Pro)

according to your digital imaging needs.

1. Turn on the camera and controller (page 27).

This causes the camera and controller to start up on the REC mode.

2. Touch “ ” (Show Icons).

3. Touch the second icon from the top (second

icon from the right in the case of portrait display

orientation) (Recording mode).

4. Touch “Auto” or “Premium Auto Pro” to select

the auto recording mode you want.

To Shoot a Snapshot

Selecting an Auto Recording Mode

Setting

REC Screen

Icon Display

Description

Auto This is the standard Auto recording mode.

Premium

Auto Pro

With Premium Auto Pro recording, the camera

automatically determines whether you are shooting a

subject or scenery, and other conditions. Premium

Auto Pro recording delivers higher image quality than

standard Auto recording.

• Some of the settings configured automatically by

Premium Auto Pro cannot be changed by you.

• It also requires more power (and runs down the

battery quicker) than Auto.

• This recording mode is recommended when you

plan to create a Highlight Photo or Highlight Movie.

Recording mode icon

35 Quick Start Basics

1. Point the camera at the subject.

If you are using Premium Auto Pro, an icon will appear

on the monitor screen describing the type of shot the

camera has detected.

• You can change display the zoom screen by holding

two fingers against the screen and spreading them

apart (page 48).

2. Press the camera or controller shutter button.

The camera will automatically adjust exposure and

focus, and then shoot the snapshot.

• Normally, shooting a snapshot will cause the

operation lamp to flash red once. Note, however,

that the operation lamp will not flash while

“Macro” is selected as the focus mode.

Shooting a Movie

Press [0] (Movie) on the camera or controller to start

movie recording.

Recording will stop if you press [0] (Movie) again.

See page 49 for details.

NOTE

• You also touch a location on the screen to focus on it,

and then shoot the image (page 53).

• You can specify the image size for snapshots. See

page 55 for more information.

• The operation lamp flashes red while movie recording is in progress.

. Shooting with the Camera Alone

You can use the camera in a stand-alone configuration without turning on the

controller or otherwise establishing a connection between it and the camera.

• If an Interval Shooting (page 44) operation or movie recording (page 49) is in

progress, it will continue to shoot images even when controller power is turned off.

To shoot a snapshot

Type of shot

+ (Telephoto) – (Wide Angle)

Shutter button

Camera

Controller

[0] (Movie)

Shutter button

Operation lamp

36 Quick Start Basics

.Shooting with Premium Auto Pro

• Some menu items are not available while Premium Auto Pro is in use (page 52).

• In addition to shutter speed and ISO sensitivity, the camera automatically executes

the following operation as required when shooting with Premium Auto Pro.

– Auto Focus is normally performed until you touch the monitor screen.

– The camera automatically determines the focus point on the screen and focuses

there.

• When shooting with Premium Auto Pro, the message “Processing Premium Auto.

Please wait...” may appear on the monitor screen. If you feel the camera is taking

too long to process data, try shooting with standard Auto instead.

• In some cases, Premium Auto Pro may not be able to interpret the shooting

environment correctly. If this happens, shoot with standard Auto.

• If “HS” is displayed, the camera will shoot a series of CS images and merge them

into a final image. Take care to avoid any camera and subject movement until

shooting of all of the CS images is complete.

37 Quick Start Basics

Use the following procedure to view snapshots on the camera’s monitor screen.

• For information about how to play back movies, see page 62.

1. Touch “ ” (PLAY) to enter the PLAY mode.

This will display one of the snapshots currently stored

in memory.

• You can also enter the PLAY mode by touching the

review image screen (page 61).

• Information about the displayed snapshot also is

included (page 10).

• You also can clear the information to view only the

snapshot (page 111).

• You can zoom the screen image by touching the monitor screen (page 63).

If you are recording a snapshot that is very important to you, it is recommended

that you zoom the image and check its details after recording it.

2. Flick left or right across the screen image to scroll through the

snapshots.

NOTE

• Pressing the controller shutter button while in the PLAY mode or while a menu

screen is displayed will switch directly to the REC mode.

• A question mark (?) will be displayed for images that cannot be displayed for some

reason.

Viewing Snapshots

“ ” (PLAY)

38 Quick Start Basics

If memory becomes full, you can delete snapshots and movies you no longer need in

order to free up storage and record more images.

IMPORTANT!

• Remember that a file (image) delete operation cannot be undone.

.To delete a single file

1. Enter the PLAY mode.

2. Touch “ ” (Show Icons).

3. Touch “ ”.

4. Touch “Delete 1 File”.

5. Flick the screen the left or right to scroll through

images until the one you want to delete is

displayed.

6. Touch “ ” (Delete).

This will delete the selected image.

.To delete all files

1. Enter the PLAY mode.

2. Touch “ ” (Show Icons).

3. Touch “ ”.

4. Touch “Delete All Files”.

5. Touch “Delete”.

This will cause the message “There are no files.” to appear.

Deleting Snapshots and Movies

39 Quick Start Basics

Operation

• If unwanted light is shining onto the lens, shade the lens with your hand when

shooting an image.

Monitor Screen when Shooting Snapshots

• Subject brightness conditions can cause monitor screen response to slow and can

cause digital noise in the monitor screen image.

• The image that appears on the monitor screen is for image composition. The actual

image will be recorded in accordance with the currently selected recording mode

(page 41).

Shooting Indoors under Fluorescent Lighting

• Minute flickering of fluorescent lighting can affect the brightness or color of an

image.

Other Precautions

• A noise reduction process is performed when ISO sensitivity is set to a high value.

This can cause the camera to take relatively longer to be ready to shoot again after

you press the shutter button. Do not perform any operation while the image

recording operation is in progress.

• Due to the characteristics of the imaging element used by the camera, very fast

moving objects in an image may appear distorted.

.Auto Focus Restrictions

• Any of the following can make proper focus impossible.

– Solid color wall or other very low contrast subject

– Strongly back lit subject

– Very shiny subject

– Blinds or other subject with a repeating horizontal pattern

– Multiple subjects at varying distances from the camera

– Subject in a dark location

– Camera movement while shooting

– Fast-moving subject

– Subjects outside the focus range of the camera

• Focus lock can be used in some recording modes. If you cannot focus properly, try

using focus lock (page 54).

Snapshot Shooting Precautions

40 Recording Images

Recording Images

Touching the monitor screen in the REC mode will display a screen for configuring

REC mode settings.

1. Press [p] (Power) to turn on the camera and enter the REC mode.

• If the camera is in the PLAY mode, touch “ ” (REC) to enter the REC mode.

2. Touch “ ” (Show Icons).

3. Touch the item whose setting you want to change.

To configure REC mode settings

Menu (page 52)*

Recording mode (page 41)

Wireless mode (page 74)

Interval Shooting mode (page 44)

PLAY mode (page 29)

*Depending on the recording mode, some of the items on the menu that

appears may not be usable.

[p] (Power)

41 Recording Images

The camera has a variety of different recording modes.

1. In the REC mode, touch the “ ” (Show

Icons).

2. Touch the recording mode icon.

3. Touch the icon of the recording mode you want

to use.

This enters the selected recording mode.

Selecting a Recording Mode

Auto Standard Auto recording mode. This is the mode normally

used for shooting (page 34).

Premium Auto

Pro

With Premium Auto Pro recording, the camera

automatically determines whether you are shooting a

subject or scenery, and other conditions. Premium Auto

Pro recording delivers higher image quality than standard

Auto recording mode (page 34).

Õ High Speed CS High Speed CS lets you shoot a burst of 30 images (page

42).

Art Shot

A variety of artistic effects help to make even common,

ordinary subjects become more novel and exciting (page

43).

Recording mode icon

42 Recording Images

Use the procedure below to shoot a burst of images.

1. In the REC mode, touch “ ” (Show Icons).

2. Touch the recording mode icon.

3. Touch “Õ” (High Speed CS).

4. Touch the scene that matches what you want to shoot.

• Touching “ ” on the screen and then touching a High Speed CS scene

displays detailed information about the scene.

• If you selected “High Speed CS 30 fps”, go to step 6.

• If you selected “High Speed CS Prerecord”, go to step 5.

5. Touch “Pre REC”.

This will start pre-recording of a group of images that will be continually updated

until you press the shutter button.

• To stop the pre-record operation of images, touch “ ”.

6. Press the shutter button.

This will shoot 30 CS images.

Shooting a Burst of Images (High Speed CS)

Scene Description

High Speed CS 30 fps High-speed shooting of 30 images in one second.

High Speed CS

Prerecord

Pressing the shutter button will store 15 pre-recorded

images along with 15 CS images that are shot after the

shutter button is pressed.

43 Recording Images

A variety of artistic effects help to make even common, ordinary subjects become

more novel and exciting.

1. In the REC mode, touch the “ ” (Show Icons).

2. Touch the recording mode icon.

3. Touch “C” (Art Shot).

4. Touch the Art Shot scene you want to use.

• Touch “ ”, “ ” to display another scene.

• Touching “ ” on the monitor screen and then touching an Art Shot scene will

display detailed information about the scene.

5. Press the shutter button to shoot.

NOTE

• If you record a movie while an Art Shot scene is selected, the Art Shot effects will

not be applied to the movie image.

• Sample images shown on Art Shot scene screens were not shot with this camera.

• An image shot with an Art Shot scene cannot be converted to a normal image

without the Art Shot effect.

Shooting with Artistic Effects (Art Shot)

Scene Description

Toy Camera Dark edges and altered hues make images look like they

were shot by a toy camera.

Soft Focus Overall blurring for a soft and romantic effect.

Light Tone Weakened contrast for a feeling of airy refinement.

Sepia Sepia tones create a decidedly retro look.

Monochrome All of the strong contrast and graininess of a black and white

print.

44 Recording Images

You can use Interval Shooting to shoot snapshots and movies automatically at a

specified interval.

Scenes marked with “ ” mark (non-Standard scenes)

• With these scenes, the “Interval” setting is a rough guide only, and the actual

interval depends on decisions made by the camera about shooting conditions.

Because of this, the actual shooting interval may be slightly different from the

setting.

• A five-second interval cannot be set for these scenes.

. To start an Interval Shooting operation

1. In the REC mode, touch the “ ” (Show Icons).

2. Touch the Interval Shooting mode icon.

3. Touch the Interval Shooting scene you want to

use.

• Touching “ ” will display a detailed explanation

about each scene. Flick upwards or downwards on

the monitor screen to scroll through scenes. When

the one you want is displayed, touch its icon.

4. Touch “ ”.

Shooting Scenes of an Activity at a Fixed Interval

(Interval Shooting)

Scene

REC Screen

Icon Display

Description

Standard Shoots at a fixed interval.

Intelligent Shoots after determining the optimum setup.

Hiking Shoots using a setup optimized for hiking.

Cycling Shoots using a setup optimized for cycling.

Snow & Water Shoots using a setup optimized for snow and

water sports.

Leisure Shoots using a setup optimized for leisure and

trips.

Interval Shooting

mode icon

45 Recording Images

5. Touch an item and then change its setting.

6. Touch “ ” (Back).

7. Touch “Start”.

This starts the operation.

• Starting Interval Shooting operation causes the camera and controller to enter

a sleep state and standby for recording of the images. This will be indicated by

the camera’s operation lamp flashing green. Note that the camera will not enter

the sleep state if “5 sec” is selected for the “Interval” setting.

• To recover from the sleep state, press any

controller button. Next, touching “ ” on the

monitor screen will display the number of recorded

images. The maximum number of shots is 9,999.

Interval Allows selection of one of the shooting intervals below.

5 sec, 15 sec, 30 sec, 1 min, 2 min

Shooting Style

t³:

Shoots five snapshots followed by a five-second movie.

³ Only:

Shoots a five-second movie. Audio is also recorded with

this setting.

t Only: Shoots a snapshot.

• When “5 sec” is selected for the “Interval” setting, the

movie recording time is two seconds.

46 Recording Images

NOTE

• Anti-shake is applied in accordance with the current camera settings. However,

image anti-shake is not applied.

• The current shooting setup, including zoom, cannot be changed while shooting

with this function.

• If the camera battery goes dead during an Interval Shooting operation, the

operation will terminate. The controller battery going dead does not affect an

ongoing operation. To stop the Interval Shooting operation in this case, hold down

[p] (Power) on the camera for about two seconds.

• If you are performing manual camera operations or if the camera is out of the sleep

state when the Interval Shooting operation reaches a shooting interval, Interval

Shooting recording for that interval will be skipped.

• Pressing the controller’s [p] (Power) button while the camera is out of the sleep

state will return to the sleep state and restart the Interval Snapshot operation.

• Initial default settings depend on the selected scene.

• If you change any settings, they are retained when you turn the camera off. To

restore initial default settings, perform a reset operation (page 115) to reset the

camera.

• Certain environments may cause the shooting interval to be longer than normal.

47 Recording Images

. To stop an Interval Shooting operation

1. On the controller, press any button to recover from the sleep state.

2. Touch “ ” icon.

3. Touch “Yes”.

This stops the Interval Shooting operation.

. To shoot images manually during an Interval Shooting operation

You can shoot snapshots and movies manually even while an Interval Shooting

operation is in progress.

1. On the controller, press any button to recover from the sleep state.

2. Perform the required controller or camera operation to shoot the image

you want.

NOTE

• You can also press the camera’s shutter button or [0] (Movie) button to shoot while

the camera is in the sleep state.

• After an Interval Shooting operation is complete, the recording mode will return to

Premium Auto Pro.

• The Review image is displayed only when “Type 1” is selected as the Review

image type (page 61).

50 Recording Images

6. Press [0] (Movie).

This will start recording.

• Monaural audio is also recorded during movie

recording while “FHD(30p)” or “STD” is selected

for the movie quality setting.

• When “FHD(30p)” or “STD” is selected for the

movie quality setting, you can touch a point on the

controller screen while movie recording is in

progress to focus on that point. Note, however,

that touching the screen will not perform a focus

operation if the Touch Shooting setting (page 53)

is “Off”.

7. Press [0] (Movie) to stop recording.

• Each movie can be up to 29 minutes or 4 GB long. Movie recording also will

stop automatically if memory becomes full before you stop movie recording.

Recording Movies with Premium Auto Pro

When Premium Auto Pro is enabled (page 34), the camera automatically make

judgments about the subject, shooting conditions, and other parameters. The result is

higher quality images than those produced by Auto recording.

• Premium Auto Pro is enabled for FHD(30p) movies and STD movies only.

• Using Premium Auto Pro uses up the battery charge more quickly than using Auto

recording.

Minimizing the Effects of Camera Movement during Movie Recording

While the image quality setting is “FHD(30p)” or “STD”, you can reduce blur due to

camera movement during movie recording by selecting the “Standard” or “Strong”

setting for “Movie Anti Shake” (page 54). Note, however, that image stabilization does

not prevent image blur due to subject movement during movie recording. Also, image

stabilization results in a narrower angle of view during movie recording. Though

selecting “Strong” for the Movie Anti Shake setting will increase the anti shake effect,

it can also increase the chance horizontal banding in the image due to light source

flicker (caused by fluorescent lighting).

High Speed Movie Recording Precautions

• When shooting a high speed movie, shoot in a well-lit environment.

• When recording a high speed movie, light source flicker can cause horizontal

bands to appear in the image. This does not indicate malfunction of the camera.

Recording time

51 Recording Images

Movie Recording Focus Position

When the focus mode setting is “AF” or “PF”, recording is performed using pan focus,

which provides a deep depth of field and suppresses image blurring. When the focus

mode setting is “Macro”, the image is automatically focused and fixed before

recording starts.

Also, you can touch a location on the monitor screen during movie recording to focus

at that location. Note, however, that touching the screen will not perform a focus

operation in the following cases.

• “Off” selected for the Touch Shooting setting

• “PF” selected for the focus setting

• “HS240” is selected for the movie quality setting

IMPORTANT!

• Spending a long time using movie recording will cause the camera to become

slightly warm to the touch. This is normal and does not indicate malfunction.

• The camera also records audio along with FHD(30p) and

STD movies. Note the following points when shooting a

movie.

– Take care that the microphone is not blocked by your

fingers, etc.

– Good audio recording results are not possible when the

camera is too far away from what you are trying to

record.

• Shooting movies for long periods in areas where temperature is relatively high can

cause digital noise (dots of light) to appear in the movie image. A rise in the

camera’s internal temperature also may force movie recording to stop

automatically. If this happens, stop recording and allow the camera to cool down,

which should cause normal operation to resume.

• Use of the camera’s built-in memory or certain types of memory cards can slow

down processing speeds. In particular, high-quality movies may not be able to be

stored correctly. A slow memory card can take too much time to record data and

result in breaks in the image and/or audio during playback.

NOTE

• Zoom operations are disabled during movie recording. To use zoom, perform the

zoom operation before you press [0] (Movie) to start recording.

• You can focus at a particular point before starting movie recording. On the

controller screen, touch the location where you want to focus, and then start

recording.

• The Make-up function cannot be used during movie recording.

Microphone

52 Advanced Recording Settings

Advanced Recording Settings

The following are menu operations you can use to configure various camera settings.

.Example Menu Screen Operation

1. In the REC mode, touch “ ” (Show

Icons).

2. Touch “MENU”.

This will display the menu screen.

• Menu contents are different in the REC mode and

PLAY mode.

3. Touch the tab where the menu item you want

to configure is located.

4. Flick upwards and downwards until you find the item whose setting

you want to change.

• To cancel and exit the menu, touch “ ” or press the controller’s shutter button.

5. Touch the item.

6. Configure the setting of the item in accordance with the screen

contents.

• To navigate back to the previous menu level, touch “ ”.

NOTE

• Depending on the recording mode, some of the items on the menu that appears

may not be usable. Nothing will happen if you touch an unusable item.

.Menu Operations in This Manual

Menu operations are represented in this manual as shown below. Touch the indicated

icons and items, and perform operations as they are indicated, from left to right.

Using the REC Menu

Tabs

Items

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab *

Touch Shooting

53 Advanced Recording Settings

Procedure

Enter the REC mode * MENU * “rREC MENU” Tab * Make-up

Make-up enables adjustment of human skin tone hues and texture, and softening of

facial shadows caused by harsh sunlight for better looking portraits.

NOTE

• Make-up is disabled while shooting with the following feature.

High Speed CS, Art Shot

Procedure

Enter the REC mode * MENU * “rREC MENU” Tab *

Touch Shooting

When you touch a location on the screen, the camera focuses on that location and

shoots.

NOTE

• When using Touch Shooting to focus, select “AF” or “Macro” as the focus mode

(page 59).

• If the focus frame remains red while the “AF Only” setting is selected, it means that

the image is not in focus (because the subject is too close, etc.) If this happens,

point the camera at the subject and try focusing again.

• Touch Shooting cannot be used while the camera is configured with either of the

settings below.

– Recording Mode: High Speed CS Prerecord

Recording Beautiful Portraits (Make-up)

Skin Tone “Tan +6” to “0 (Off)” to “Light +6”

Smooth Skin “0 (Off)” to “+12 (Max.)”

Shooting by Touching the Monitor Screen (Touch Shooting)

AF + Shoot The camera performs Auto Focus at the spot you touch and

then shoots.

AF Only The camera performs Auto Focus at the spot you touch and

locks focus (Focus Lock).

Off Touch Shooting disabled.

54 Advanced Recording Settings

Using Focus Lock

Use “focus lock” when you want to focus on a particular

person or object. To use focus lock, configure the

camera settings below.

Touch Shooting: AF Only

Focus Mode: AF or Macro

1. Touch the subject you want to focus on.

2. When you are ready to shoot the image,

press the shutter button.

NOTE

• Focus lock also locks exposure (AE) and white balance.

• Focus lock is cancelled if you touch the screen, or about five minutes after focus

lock is activated.

Procedure

Enter the REC mode * MENU * “rREC MENU” Tab *

Movie Anti Shake

You can reduce blur due to camera movement during movie recording by selecting

the (Standard) or (Strong) setting. However, image anti-shake is not used.

Also, Anti Shake results in a narrower angle of view during movie recording.

NOTE

• Movie Anti Shake is not supported during High Speed Movie recording.

Reducing Blur Due to Camera Movement During Movie

Recording (Movie Anti Shake)

Focus frame

Subject to be focused on

55 Advanced Recording Settings

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab * Image Size

This setting can be used to configure snapshot image size.

• The initial factory default image size setting is 12M (12 million pixels).

• You should regard the print paper sizes suggested here as guidelines only (200 dpi

print resolution).

.Pixels and image size

A digital camera image is a collection of small

dots called “pixels”. The more pixels there are

in an image, the more detail there will be.

However, you generally can do with fewer

pixels when printing an image (L size)

through a print service, attaching an image to

e-mail, when viewing the image on a

computer, etc.

The size of an image indicates how many

pixels it contains, and is expressed as horizontal pixels

xvertical pixels.

• Note that larger images have more pixels, so they take up more memory space.

• For information about image size and number of images that can be stored, see

page 155.

• For information about movie image size, see page 155.

Changing the Image Size (Image Size)

Image Size

(Pixels)

REC Screen

Icon Display

Suggested Print

Size and

Application

Description

12M

(4000x3000) Poster Print

Good detail for better clarity even

for images cropped from the

original on a computer, etc.

(2560x1920) A4 Print Good detail

Pixel

56 Advanced Recording Settings

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab * Movie Quality

This setting can be used to configure movie image quality settings and to select either

normal movie recording or High Speed Movie recording. For information about movie

image quality settings, see page 49.

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab * Brightness

You can manually adjust an image’s exposure value (EV value) before shooting it.

The exposure compensation value you set remains in effect until you change it.

– Exposure Compensation Range: –2.0 EV to +2.0 EV

– Unit: 1/3 EV

• To cancel exposure compensation, change the EV value to 0.0.

NOTE

• When shooting under very dark or very bright conditions, you may not be able to

obtain satisfactory results even after performing exposure compensation.

Movie Image Quality Settings (Movie Quality)

Correcting Image Brightness (Brightness)

Decreases the EV value. A lower EV

value is best for dark-color subjects and

for shooting outdoors on a clear day.

Increases the EV value. A higher EV

value is best for light-colored subjects

and backlit subjects.

57 Advanced Recording Settings

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab *

White Balance

You can adjust white balance to match the source of light available where you are

shooting and avoid the blue cast that results when shooting outdoors when it is

cloudy, and the green cast that results when shooting under fluorescent lighting.

1. Touch the type of white balance you want to select.

You can see the affect of the white balance setting you select on the monitor

screen.

• When “‡Auto WB” is selected for the white balance setting, the camera

automatically determines the white point of the subject. Certain subject colors

and light source conditions can cause problems when the camera tries to

determine the white point, which makes proper white balance adjustment

impossible. If this happens, select the white balance setting that matches your

shooting conditions (Daylight, Overcast, etc.).

• When shooting with Premium Auto Pro, the white balance setting is fixed at

“‡Auto WB”.

Adjusting White Balance (White Balance)

Setting Description

Auto WB Configures the camera to adjust white balance

automatically

Daylight For shooting outdoors on a clear day

Overcast For shooting outdoors on an overcast rainy day, in the

shade, etc.

Shade For shooting on a clear day in the shade of trees or

buildings

Day White Fl. For shooting under white or day white fluorescent

lighting

Daylight Fluor For shooting under daylight fluorescent lighting

Tungsten For shooting under light bulb lighting

Manual WB

For configuring the camera manually to suit a particular

light source.

Touch “·Manual WB”.

In the location where you plan to

shoot, point the camera at a

blank white piece of paper so it

fills the entire monitor screen.

Touch an area of the screen

where no icon is located.

The white balance setting is retained even if you turn

off the camera.

‡

“

†

–

Blank white paper

58 Advanced Recording Settings

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab * ISO

ISO sensitivity is a measure of sensitivity to light.

• Since higher ISO sensitivity values tend to result in digital noise in images, the

camera performs a noise filtering process. Because of this, it may take relatively

longer for the camera to finish recording an image after it is shot. You will not be

able to perform any operation while image recording is in progress.

• When shooting with Premium Auto Pro, the ISO setting is fixed at “Auto”.

Specifying ISO Sensitivity (ISO)

Setting Description

Auto Adjusts sensitivity automatically according to conditions

ISO64 Lower

sensitivity

Higher

sensitivity

Slow shutter speed

Fast shutter speed (Set

for shooting in dimly lit

areas.)

Less noise

Some coarseness

(increased digital noise)

ISO100

ISO200

ISO400

ISO800

ISO1600

ISO3200

59 Advanced Recording Settings

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab * Focus

Changing to a different focus mode can help to achieve better focus.

*1 The focus range is the distance from the lens surface.

*2 Focus remains fixed at the position where it was when movie recording started.

*3 Some time may be required to focus.

NOTE

• The focus mode is fixed as “AF” (Auto Focus) while shooting with Premium Auto

Pro.

Selecting a Focus Mode (Focus)

Settings

REC Screen

Icon Display

Type of Shot Focus Mode Approximate Focus Range

Snapshot SnapshotMovies Movies

(Auto

Focus)

None

General

recording

Automatic

Fixed

focal point

10 cm to

(infinity)

(3.9"

)

46 cm to

(infinity)

(18.1"

)

Macro

Close ups Automatic 3 cm to 10 cm

(1.2" to 3.9")

3 cm to 10 cm

(1.2" to 3.9")

2, 3

PF (Pan

Focus)

Shooting

with a

relatively

wide focus

range

Fixed

focal point

Fixed

focal point

55 cm to

(infinity)

(21.7"

)

46 cm to

(infinity)

(18.1"

)

61 Advanced Recording Settings

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab * Review

While Review is turned on, the camera will display an image immediately after it is

recorded.

NOTE

• A Type 2 review image is displayed when “High Speed CS” is selected as the

recording mode, even if “Type 1” is selected for the Review setting.

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab * Grid

Selecting “On” displays grid lines on the monitor screen. The grid lines provide

references that help you keep the camera vertically and horizontally straight.

Turning on Image Review (Review)

Type 1 Displays a full-screen view of the image for about one second.

Type 2

Displays a review image in the lower left corner (when the controller is

in landscape orientation) or the upper left corner (in portrait orientation)

of the controller monitor screen. Touching the Review image will enter

the PLAY mode and display a full-screen view of the image.

Off Turns off review image display

Displaying a Grid on the Monitor Screen (Grid)

62 Viewing Snapshots and Movies

Viewing Snapshots and Movies

See page 37 for the procedure for viewing snapshots.

1. Touch “ ” (PLAY) to enter the PLAY mode.

2. Flick left or right across the screen image to

scroll through the movies until the one you

want is displayed.

3. Touch “ ” (Movie) to start playback.

• To switch to full-screen view, touch the monitor screen.

NOTE

• Playback may not be possible for movies not recorded with this camera.

• When a movie is played back on the camera, the audio output from the camera

speaker will be out of sync with the video image. This does not indicate any

problem with the movie file. Also, playback on the camera uses a low frame rate.

Send the movie to a smartphone for better movie playback results.

Viewing Snapshots

Viewing a Movie

Movie icon:

Movie recording time

Image quality

Playback in progress Playback paused

Touch “ ”.

Progress bar

65 Viewing Snapshots and Movies

9. Touch “Yes”.

This creates and save the Highlight Movie, and displays it on the monitor screen.

• Touching “Cancel” while creation of a Highlight Movie is in progress will stop

Highlight Movie creation. No movie is saved if you stop Highlight Movie

creation.

NOTE

• An image whose highlight score is “0” is never included in a Highlight Movie.

• A Highlight Movie is FHD(30p) movie quality, with an aspect ratio of 16:9. If an

image with an aspect ratio that is not 16:9 is incorporated into a Highlight Move, the

top and bottom of the image will be cropped as required.

• If a portrait orientation image is incorporated in to a Highlight Movie, there will be

black bands on the left and right of the image.

• When there is a total of more than 9,999 snapshot and movie files shot on the

same date, Highlight Movie will select photos and movies from the files numbered

1 to 9999.

• Depending on the number of files and other factors when a Highlight Movie is being

created, the creation operation may take some time.

• Only FHD(30p) quality movies that have been recorded with this camera or with a

CASIO EX-FR10 camera can be used in a Highlight Movie. Even if a movie was

recorded with this camera, it cannot be used in a Highlight Movie if it is HS240 or

STD quality.

66 Viewing Snapshots and Movies

You can configure camera settings to automatically select

snapshot highlights and generate a collage of them. The

snapshots included in a Highlight Photo are selected

automatically based on their high light scores and shooting

condition information recorded along with the snapshots.

• You can use the Highlight Score function (page 67) to

change the highlight score of a snapshot.

1. In the PLAY mode, touch “ ” (Show Icons).

2. Touch the “ ” (Edit) icon.

3. Touch “ ”.

• Touching “ ” will display a detailed explanation about image editing functions.

Flick upwards or downwards on the monitor screen until “Highlight Photo” is

displayed, and then touch its icon.

4. Select how images should be chosen for conversion to a Highlight

Photo.

5. Touch “ ”, “ ” to select the date or Interval Shooting for which you

want to create a Highlight Photo.

6. Touch “ ”, “ ” to display the layout you want to use, and then

touch it.

7. Touch “Apply”.

This displays the Highlight Photo and saves it in camera memory.

• Touching “Cancel” while creation of a Highlight Photo is in progress will stop

Highlight Photo creation.

• The screen that appears after the image is saved includes a “ ” (Shuffle)

icon. Touching the shuffle icon creates a Highlight Photo using different

snapshots. This also deleted the previously created Highlight Photo.

8. Touch “ ” to exit Highlight Photo.

Creating a Collage of a Day’s Snapshots (Highlight Photo)

Date Images are selected from among those shot on a specific

date.

Interval Group Images are selected from among those in a group of

Interval Shooting images (page 44).

67 Viewing Snapshots and Movies

NOTE

• An image whose highlight score is “0” is never included in a Highlight Photo.

• When there are more than 9,999 snapshots shot on the same date stored on the

memory card, Highlight Photo will select photos from those numbered 1 to 9999.

• The Highlight Photo operation may not be possible while battery power is low.

You can use the procedure below to change the highlight score of a snapshot or

movie.

1. In the PLAY mode, touch “ ” (Show Icons).

2. Touch the “ ” (Edit) icon.

3. Touch the “ ” (Highlight Score) icon.

4. Flick the screen upwards or downwards to

scroll through highlight scores until the one

you want to delete is displayed, and then

touch to select it.

5. Touch the score you want to assign to the selected image.

• You can flick the screen left or right to scroll to another image and change its

score as well.

6. After changing the highlight score of the image, touch “ ” to return

to the main screen.

NOTE

• The highlight score function can be used only with snapshots and movies recorded

with this camera.

• The highlight score of a protected image cannot be changed.

Changing the Highlight Score of an Image (Highlight Score)

Highlight

Score Description

No score assigned (default)

An image with this score may be selected for a Highlight Snapshot or

Highlight Movie.

An image with this score is given priority for Highlight Snapshot or

Highlight Movie selection.

An image with this score is never selected for a Highlight Snapshot or

Highlight Movie.

68 Viewing Snapshots and Movies

This function creates a Time Lapse Movie up to 10 minutes long by combining

snapshots shot with the camera on a particular date, in the order they were shot.

1. In the PLAY mode, touch “ ” (Show Icons).

2. Touch the “ ” (Edit) icon.

3. Touch the “ ” (Time Lapse) icon.

• Touching “ ” will display a detailed explanation about image editing functions.

Flick upwards or downwards on the monitor screen until “Time Lapse” is

displayed, and then touch its icon.

4. Select how images should be chosen for conversion to a Time Lapse

Movie.

5. Touch “¥”.

6. Touch an item and then change its setting.

7. After settings are the way you want, touch “ ” (Back) to return to the

screen in step 5.

8. Use (touch) the up and down arrows (“ ”, “ ”) to display the

recording date or Interval Shooting of the images you want to use to

create a Time Lapse Movie.

9. Touch “Yes”.

This creates and displays the Time Lapse Movie.

• Touching “Cancel” while creation of a Time Lapse Movie is in progress will

cancel the creation process.

Creating a Time Lapse Movie (Time Lapse)

Date Create a Time Lapse Movie for a specific date.

Interval Group Create a Time Lapse Movie for group of Interval Shooting

images (page 44).

Playback Speed

Specify the playback time of each image. Selecting “Slow”

specifies a longer playback time for each image, while

“Fast” specifies a shorter playback time.

Music Select the background music you want to use.

69 Viewing Snapshots and Movies

NOTE

• A Time Lapse Movie is FHD(30p) movie quality, with an aspect ratio of 16:9. If an

image with an aspect ratio that is not 16:9 is incorporated into a Time Lapse Movie,

the top and bottom of the image will be cropped as required.

• If a portrait orientation image is incorporated in to a Time Lapse Movie, there will be

black bands on the left and right of the image.

• When there is a large number of images, this function will stop processing when

the Time Lapse Movie reaches a length of 10 minutes. Subsequent images will not

be converted to a Time Lapse Movie.

• Highlight Photos are not included in Time Lapse Movies.

• Depending on the number of files and other factors when a Time Lapse Movie is

being created, the creation operation may take some time.

70 Other Playback Functions (PLAY)

Other Playback Functions (PLAY)

The following are menu operations you can use to configure various camera settings.

.Example Menu Screen Operation

1. In the PLAY mode, touch “ ” (Show

Icons).

2. Touch “MENU”.

This will display the menu screen.

• Menu contents are different in the REC mode and

PLAY mode.

3. Touch the tab where the menu item you want

to configure is located.

4. Touch the item whose setting you want to change.

5. Configure the setting of the item in accordance with the screen

contents.

• To navigate back to the previous menu level, touch “ ”.

.Menu Operations in This Manual

Menu operations are represented in this manual as shown below. Touch the indicated

icons and items, and perform operations as they are indicated, from left to right.

Using the PLAY Menu

Tabs

Items

Procedure

Enter the PLAY Mode * MENU * Rotation

71 Other Playback Functions (PLAY)

Procedure

Enter the PLAY Mode * MENU * Rotation

1. Flick left or right to display the image you want to rotate.

2. Touch “ ”.

This will rotate the image 90 degrees to the left.

3. When the image is in the orientation you want, touch “ ”.

NOTE

• Note that this procedure does not actually change the image data. It simply alters

how the image is displayed on the camera’s monitor screen.

Rotating an Image (Rotation)

72 Connecting the Camera with a Smartphone

(Wireless Connection)

Connecting the Camera with a Smartphone

(Wireless Connection)

Your camera has both Bluetooth wireless technology and wireless LAN capabilities

built in. After establishing a wireless connection with a smartphone, you can perform

the operations described in the table below. Requires installation of the EXILIM

Connect app on your smartphone.

• Your camera is a Bluetooth

Smart

device.

• Your camera can connect using

Bluetooth wireless technology with a

smartphone that supports Bluetooth

Smart. Note that the Bluetooth wireless

technology that connects your camera

with a smartphone is different from the

Bluetooth wireless technology that connects the camera with the controller.

Controlling Your Camera with a Smartphone

With this function: You can do this:

Auto Send

Images can be automatically sent to a

smartphone that has been Bluetooth paired with

the camera (page 82).

Shoot with phone

Remotely control and shoot with the camera

using a smartphone (page 79).

Send to phone

Send snapshots and movies recorded with your

camera to your smartphone.

After sending an

image to a smartphone, you can then upload it

from the smartphone to a social networking

service (page 80).

73 Connecting the Camera with a Smartphone

(Wireless Connection)

IMPORTANT!

• Inside an aircraft or anywhere else where use of wireless communication is

restricted or prohibited, do not use this camera.

• Some smartphone models may not be able to play back movie files from your

camera.

• While there is a connection between the camera and smartphone, recording by

pressing the camera’s shutter button or [0] (Movie) button is not supported.

• Depending on your smartphone model, its operating system version, and/or its

remaining storage capacity can cause failure of a movie or snapshot save

operation. Receiving a camera file, perform the required operation on your

smartphone to check if the file was stored properly.

• A movie received on an Android™ terminal:

– Movies are not displayed by Gallery app. Movies are stored in a folder named

EXILIM Connect.

– A separate movie player is required to playback movies (whose files have the file

name extension MOV).

– Depending on your movie player, you may not be able to playback movies and/

or audio.

• Images recorded on another manufacturer’s camera cannot be sent using this

function.

NOTE

• Note that using wireless functions requires more battery power usage than normal.

Make sure that the camera battery is sufficiently charged before starting a wireless

LAN operation.

• The operating range depends on the local communication environment and on the

type of smartphone you are connected to.

View on phone

View snapshots stored in camera memory on a

smartphone, and copy snapshots and movies

to a smartphone for viewing. You can also view

snapshots and movies in camera memory on a

computer, and copy them to a computer (page

81).

With this function: You can do this:

74 Connecting the Camera with a Smartphone

(Wireless Connection)

.About EXILIM Connect

For detailed information about EXILIM Connect, refer to the EXILIM Connect User’s

Guide (which you can download at the website below).

http://www.exilim.com/manual/

• Note that to view the EXILIM Connect User’s Guide (PDF), you will have to install

Adobe Reader. Consult CASIO authorized service center if you are unable to open

to display the PDF format User’s Guide.

• Note that EXILIM Connect User’s Guides may not be available in all languages. If

you cannot find a EXILIM Connect User’s Guide in your native language, please

use a version in another language.

Your camera has a variety of different wireless

modes. Select the wireless mode that suits your

specific requirements.

1. Touch “ ” (Show Icons).

2. Touch the “ ” (Wireless) icon.

This will display the wireless mode screen.

3. Touch the wireless mode you want.

• To exit the wireless mode, touch “ ”.

Using a Wireless Mode

Send to phone

Select to view images you shoot with the camera on a smartphone (pages 80,

81).

Pairing

Select this mode to establish a Bluetooth wireless technology connection

between the camera and a smartphone (page 76).

Shoot with phone

Select this mode for remote control of image recording from a smartphone

(page 79).

Wireless settings

Select this mode to configure wireless settings (page 82).

“ ” (Wireless)

75 Connecting the Camera with a Smartphone

(Wireless Connection)

Installing the EXILIM Connect Smartphone app on your smartphone makes it

possible to remotely control the camera from your smartphone and to send images

recorded with the camera to your smartphone. Search the EXILIM Connect app on

Google Play ™ or App Store and install it on your smartphone.

. App operation guarantees

No guarantees are made concerning the ability to operate the EXILIM Connect app

on any particular smartphone or tablet.

IMPORTANT!

• App functions and the required operating environment are subject to change

without notice.

. Android terminal

1. Open “Play Store” (Google Play).

2. In the search field, type “EXILIM Connect”.

3. Install “EXILIM Connect”.

. iPhone (iOS)

1. Open “App Store”.

2. In the search field, type “EXILIM Connect”.

3. Install “EXILIM Connect”.

Getting Ready to Establish a Connection between a

Smartphone and Your Camera

For information about OS versions (Android and iOS) supported by the

EXILIM Connect app, visit the Google Play or the App Store download site, or

the Official CASIO Digital Camera Website (http://www.exilim.com/).

Installing the EXILIM Connect App on Your Smartphone

76 Connecting the Camera with a Smartphone

(Wireless Connection)

The first time you establish a wireless connection between the camera and a

smartphone, you need to use the procedure below to configure wireless connection

settings. This operation is required for the first connection only.

. Smartphone that supports Bluetooth Smart

Connecting the camera to a smartphone using Bluetooth wireless technology

(pairing) makes it simple to configure wireless connection settings.

IMPORTANT!

• Performing this operation automatically configures your smartphone’s wireless

LAN connection settings (page 77).

• Your camera can be paired with a single smartphone at one time.

• Some smartphone models may not be compatible with this camera.

• If you want to re-pair the camera with the smartphone it is already paired with, first

unpair them and then pair again. Re-pairing the camera and smartphone will result

in all pending unsent images to remain unsent.

Camera (Controller) Operation

1. Touch the “ ” (Wireless) icon.

This will display the wireless mode screen.

2. Touch “Pairing”.

3. Touch “Start”.

• You can start pairing by performing an operation on the camera, without using

the controller.

On the camera, hold down [p] (Power) for about two seconds to turn off

power.

On the camera, hold down [p] (Power) for about six seconds.

The camera’s operation lamp will flash amber.

Smartphone Operation

4. Start up the “EXILIM Connect” app.

5. Tap “Pairing”.

6. Perform the required connection operation as instructed by the app

and your smartphone.

This establishes a Bluetooth wireless technology connection between the camera

and smartphone.

• For information about how to configure wireless connection settings, refer to

the EXILIM Connect manual (page 74).

Establishing a Wireless Connection for the First Time

77 Connecting the Camera with a Smartphone

(Wireless Connection)

NOTE

• “Auto Send” (page 82) will be turned on after you configure wireless connection

settings on the camera and smartphone.

• Turning off the camera also terminate the Bluetooth wireless technology

connection.

. Smartphone that does not support Bluetooth Smart

Configure smartphone wireless LAN connection settings (input the camera SSID and

password).

1. Touch the “ ” (Wireless) icon.

2. Touch “Shoot with phone”.

3. Touch “Start”.

This will enable connection with a smartphone and the

camera will display a screen for input of an SSID and

password, and camera’s wireless LAN connection

lamp will flash blue.

4. For the smartphone’s Wi-Fi settings, enter the camera’s SSID and

password to establish a wireless LAN connection between the camera

and smartphone.

When the smartphone establishes a wireless LAN connection with the camera,

the camera’s wireless LAN connection lamp lights blue and the message “Start

up the phone app.” appears on the controller’s monitor screen.

• What you need to do to establish a wireless LAN connection depends on the

type of smartphone you are using. For details about how to establish a wireless

LAN connection see the user documentation that comes with your smartphone.

• The camera SSID (which cannot be changed) and password (initial default) are

shown below.

SSID: FR100-XXXXXX (6-character alphanumeric ID)

Password: 00000000

5. On the smartphone, start up “EXILIM Connect”.

NOTE

• You can also use the procedure below to establish a wireless LAN connection

between the camera and smartphone.

On the camera, hold down [p] (Power) for about two seconds to turn off power.

On the camera, while holding down [0] (Movie), hold down [p] (Power) for

about one second.

The camera’s wireless LAN connection lamp will flash blue.

On the smartphone, select the camera’s SSID.

SSID

Password

78 Connecting the Camera with a Smartphone

(Wireless Connection)

. What to do if you are unable to establish a wireless LAN connection

between the camera and a smartphone.

This problem may be caused when the smartphone is already wirelessly connected to

one of the networks or devices below. Go to your smartphone’s Wi-Fi settings and

select this camera’s SSID.

– Household wireless LAN

– Public wireless LAN

– Portable wireless LAN device

79 Connecting the Camera with a Smartphone

(Wireless Connection)

This function lets you remotely shoot a snapshot or movie with the camera using a

smartphone. You also can perform remote zoom and other operations as well.

. Bluetooth Wireless Technology Connection

1. Perform one of the operations below.

– Enter the sleep mode.

 Turn on the camera and controller.

 On the controller, press [p] (Power).

This will enter the sleep mode, which is indicated by the camera’s operation

lamp slowly flashing green.

– Display the wireless mode screen.

 Touch “ ” (Show Icons).

 Touch the “ ” (Wireless) icon.

2. On the smartphone, start up the “EXILIM Connect” app.

3. On the smartphone, tap “Remote Capture”.

4. Compose the image on the smartphone’s screen as you shoot.

For information about how to use “Shoot with phone”, refer to the EXILIM Connect

manual (page 74).

. Cannot Connect with Bluetooth Wireless Technology

1. Touch the “ ” (Wireless) icon.

2. Touch “Shoot with phone”.

3. Touch “Start”.

• If there is a wireless LAN connection between the smartphone and camera,

advance to step 5 of this procedure.

4. For the smartphone’s Wi-Fi settings, select the SSID displayed on the

camera and establish a wireless LAN connection between the camera

and smartphone.

5. On the smartphone, start up the “EXILIM Connect” app.

6. Compose the image on the smartphone’s screen as you shoot.

For information about how to use “Shoot with phone”, refer to the EXILIM Connect

manual (page 74).

Using a Smartphone as a Camera Remote Controller

(Shoot with phone)

80 Connecting the Camera with a Smartphone

(Wireless Connection)

You can select one more snapshot and/or movie file in camera memory and send it to

a smartphone. You can select up to 50 files, totaling no more than 500MB for a single

send. After sending an image to a smartphone, you can then upload it to a social

networking service.

1. Touch the “ ” (Wireless) icon.

2. Touch “Send to phone”.

3. Touch “Send Selected Image”.

4. Touch the image you want to send to the smartphone.

Selecting the image of a file causes its check box to become selected.

• To exit the send image to smartphone operation, touch “Cancel”.

5. After selecting the images of all of the files you want to send to the

smartphone, touch “OK”.

For information about how to use “Send Selected Image”, refer to the EXILIM

Connect manual (page 74).

Sending a Snapshot or Movie File from Camera Memory to a

Smartphone (Send Selected Image)

81 Connecting the Camera with a Smartphone

(Wireless Connection)

You can connect the camera to a smartphone over wireless LAN to view and

download snapshots and movies in camera memory on up to eight connected

smartphones. You can also view snapshots and movies in camera memory on a

computer, and copy them to a computer. A smartphone does not need to have the

EXILIM Connect app installed in order to access camera images using this function.

1. Touch the “ ” (Wireless) icon.

2. Touch “Send to phone”.

3. Touch “View on phone”.

This establishes a connection between the smartphone and camera, and displays

a URL.

• If the message “Connect your phone to the access point below.” remains on

the camera’s monitor screen, change the smartphone’s Wi-Fi settings so your

camera is selected for connection (page 76).

4. On the smartphone, start up its browser app.

• Accessing the URL displayed by the camera will

display an image stored in camera memory.

• To exit the wireless LAN function, touch “Exit” on

the camera’s monitor screen.

IMPORTANT!

• Some smartphone models may not be able to play back movie files.

NOTE

• You can also view image in camera memory on a computer’s browser by

establishing a wireless LAN connection with the computer.

• For information about how to start up EXILIM Connect and view images, refer to

the EXILIM Connect manual (page 74). Note that the operation you need to

perform depends on whether or not there is a Bluetooth wireless technology

connection with the smartphone.

Viewing Snapshots and Movies in Camera Memory on a

Smartphone (View on phone)

URL

82 Connecting the Camera with a Smartphone

(Wireless Connection)

This section explains wireless mode operations and setting items.

1. Touch the “ ” (Wireless) icon.

This will display the wireless mode screen.

• Pressing the shutter button will return to the screen that was displayed before

the wireless mode screen.

2. Touch “Wireless settings”.

This will display the wireless setting screen.

3. Touch the item you want to configure.

4. Change the setting of the selected item.

• Changing a setting returns to the wireless mode screen.

Procedure

“ ” (Wireless) * Wireless settings * Auto Send

While “On” is selected for this setting, images are sent to the paired smartphone

automatically. Images are sent to the smartphone while the camera is in the sleep

mode. If there is no wireless connection between the camera and smartphone, the

images will be sent as soon as a connection is established.

• The camera’s wireless LAN connection lamp will be flashing or lit while an image

send operation is in progress. The lamp will go out after the image send operation

is complete.

IMPORTANT!

• Auto Send cannot be enabled unless the camera is paired with a smartphone

(page 76).

• Images recorded with Interval Shooting cannot be automatically sent to a

smartphone using Auto Send.

Configuring Wireless Connection Settings

Having Images Shot with the Camera Sent to a Smartphone

Automatically (Auto Send)

83 Connecting the Camera with a Smartphone

(Wireless Connection)

NOTE

• Auto Send can be used only with a smartphone that supports Bluetooth Smart.

Both a Bluetooth and wireless LAN connection are required between the camera

and smartphone to auto send camera images.

• You can specify the size of the image sent to the smartphone using “Resize When

Sending” (page 84).

• You can use the smartphone apps below to view snapshots after sending them.

– iPhone: Camera Roll

– Android terminal: Gallery, Photo, or another photo browser app

• Images shot while the Auto Send setting is “On” will be sent to the smartphone,

even if the Auto Send setting is changed to “Off” before they are sent.

• If the connection between the camera and smartphone is terminated while there

are still unsent images, Auto Send will be cancelled. The next time the camera and

smartphone are turned on and the camera enters the Sleep Mode, the Auto Send

operation will restart.

• If you delete an image that has not yet been sent to the smartphone, it will not be

included in the next Auto Send.

Procedure

“ ” (Wireless) * Wireless settings * Auto Send File Settings

Specifies the files to be sent to a smartphone by Auto Send.

IMPORTANT!

• The maximum size movie file that can be sent by Auto Send is 100 MB.

• Auto Send File Settings cannot be configured unless the camera is paired with a

smartphone (page 76).

Specifying Images to be Sent by Auto Send

(Auto Send File Settings)

T » Snapshots and movies are sent.

T Only Only snapshots are sent.

84 Connecting the Camera with a Smartphone

(Wireless Connection)

Procedure

“ ” (Wireless) * Wireless settings * Resize When Sending

This feature can be use to resize snapshots before they are sent to a smartphone

using “Shoot with phone” or “Send to phone”.

NOTE

• Resizing is supported for images recorded with this model camera only.

Procedure

“ ” (Wireless) * Wireless settings * WLAN password

Use procedure to change the password you used when establishing a wireless LAN

connection between the camera and a smartphone.

IMPORTANT!

• Before changing the wireless LAN password, unpair the camera from its paired

smartphone (page 85).

1. Touch the password digit you want to change.

2. Touch “ ” or “ ” to change the currently selected digit.

3. When the password is the way you want, touch “OK”.

Resizing Snapshots before Sending Them to a Smartphone

(Resize When Sending)

Images are converted to 3M size before being sent.

• If an original image is 3M size or smaller, it is sent without

resizing.

Off Images are sent in the size they were originally recorded.

Changing the Camera Password for Wireless LAN Connection

(WLAN password)

85 Connecting the Camera with a Smartphone

(Wireless Connection)

NOTE

• Changing the wireless LAN password will terminate the connection with the

smartphone. To reconnect with the smartphone, configure wireless connection

settings (page 76). If your smartphone does not support Bluetooth Smart, perform

the operations below to change your smartphone’s Wi-Fi settings.

– iPhone:

Tap the right arrow of the field where the SSID of the camera is displayed in the

Wi-Fi settings to delete network settings. After deleting, select the camera SSID

again and input the new password.

– Android terminal:

Tap the field where the SSID of the camera is displayed in the Wi-Fi settings and

select Forget. Select the camera SSID again and input the new password.

Procedure

“ ” (Wireless) * Wireless settings * Unpairing

Unpairs the camera from a smartphone.

To use the camera with a different smartphone, first unpair it from the current

smartphone.

NOTE

• When unpairing, be sure also to perform the unpairing operation on the

smartphone as well. For details, refer to the EXILIM Connect User’s Guide (page

74).

• Unpairing the camera from a smartphone will result in all pending unsent images to

remain unsent.

Unpairing the Camera from a Smartphone (Unpairing)

86 Using Two Cameras at the Same Time (Multi

Camera Mode)

Using Two Cameras at the Same Time

(Multi Camera Mode)

You can register two cameras on the controller and operate them both at the same

time or individually.

What you can do with two cameras

Feature Description

Simultaneous shooting with

two cameras

You could point one camera at yourself and the

other camera at a scene, and simultaneously

record the scene and your reaction to it.

Possibilities are unlimited!

Switching between two

cameras

You can switch between the two cameras as

desired.

Interval Shooting You can set up two cameras to shoot

snapshots and/or movies at fixed intervals.

Two-camera playback You can simultaneously play back snapshots

and/or movies you recorded with two different

cameras.

87 Using Two Cameras at the Same Time (Multi

Camera Mode)

IMPORTANT!

• In addition to the camera that comes with the controller, you can also register the

camera model below on the controller.

– EX-FR100* or EX-FR200 camera

*Update the camera’s firmware to the latest version.

Perform the steps below on the second camera before trying to register it on the

controller.

1. Charge the camera’s battery (page 20).

2. Prepare a memory card for the camera (page 31).

To use a second camera, you need to register it on the controller.

. To register a second camera on the controller

1. If there is a memory card loaded in the second camera, remove it.

2. On the menu screen, touch the “¥ Setup” tab.

3. Touch “Multi-Pairing”.

4. Touch “Add”.

5. Touch “Start” to start registration of the camera.

6. While holding down the shutter button of the camera you want to

This will cause the operation lamp to flash orange to indicate that camera

registration has started.

When the camera is registered successfully, a message appears and then the

Multi Image screen appears.

Preparing a Second Camera to be Registered on the

Controller

Registering a Second Camera on the Controller

88 Using Two Cameras at the Same Time (Multi

Camera Mode)

NOTE

• Up to two cameras can be registered at one time. To add a new camera while two

cameras are already registered, you will need to first unregister one of the

registered cameras.

• A message will appear if camera registration fails, and then the display will return to

the screen that was shown before you touched the “¥ Setup” tab. If this happens,

perform the camera registration procedure again from step 1.

• You can also use the procedure below to register a camera on a controller.

If the camera has a memory card loaded, remove it.

While holding down the camera shutter button, hold down the [p] (Power)

button for at least one second.

While holding down the controller shutter button, hold down the [p] (Power)

button for at least six seconds.

This will cause the operation lamps of the camera and the controller to flash

orange to indicate that camera registration has started.

. To unregister a camera

1. Turn on the controller and one of the cameras.

This will establish a connection between the controller and camera you turned on.

2. On the menu screen, touch the “¥ Setup” tab.

3. Touch “Multi-Pairing”.

4. Touch “Unpair”.

The names of the cameras registered on the controller will appear on the display

in sequence.

5. Touch the name of the camera you want to unregister.

6. Touch “Yes”.

The camera you selected will be unregistered and then the display will return to

the screen that was shown before you touched the “¥ Setup” tab.

A message will appear if the camera you select is connected to the controller. If

this happens, touch “Yes” to unregister.

NOTE

• You cannot unregister either camera while two cameras are connected to a single

controller (Multi Camera Mode). In this case, you need to turn off either of the

cameras, and then perform the procedure above to unregister.

89 Using Two Cameras at the Same Time (Multi

Camera Mode)

. Camera Connection Priority (Camera Priority)

Turning on the controller when there are two cameras registered will cause the

controller to try and connect with one of the cameras. You can use the procedure to

specify a “main camera”, which is the one the controller will always connect with first.

1. On the menu screen, touch the “¥ Setup” tab.

2. Touch “Multi-Pairing”.

3. Touch “Camera Priority”.

The names of the cameras registered on the controller will appear on the display

in sequence.

4. Touch the name of the camera you want to specify as the main camera.

5. Touch “Yes”.

This will specify the camera you selected as the main camera (Camera 1). Next,

the display will return to the screen that was shown before you touched the “¥

Setup” tab.

90 Using Two Cameras at the Same Time (Multi

Camera Mode)

“ ” will be displayed on the controller when there are two cameras registered on it.

Touch “ ” to start the connection operation with Camera 2.

Connecting the controller with two cameras will enter the Multi Camera Mode, in

which the controller can control both cameras. The first that connects with the

controller is Camera 1 (main camera), while the second one is Camera 2.

NOTE

• Both of the cameras must be turned on to use the Multi Camera Mode. A camera

will not be able to connect to the controller if it is not turned on.

• The date and time settings of Camera 2 will automatically be synced with the date

and time of Camera 1.

• In the case of portrait orientation, the Multi Image screen will show images above

and below instead of left and right.

Selecting the Multi Image Screen

On the Single Image screen, touch “ ” (Multi Image icon).

Selecting the Single Image Screen

On the Multi Image screen, touch “ ” or “ ” (Single Image icon). This will display

the Single Image screen of the camera whose icon you touched.

Multi Camera Mode

Multi Image Screen Single Image Screen

This view simultaneously shows the

record or playback images of both

cameras side by side.

The Camera 1 image is on the left, while

the Camera 2 image is on the right.

This view shows a full-screen view of

either the Camera 1 or the Camera 2

image.

91 Using Two Cameras at the Same Time (Multi

Camera Mode)

. Exiting the Multi Camera Mode

Exit the Multi Camera Mode whenever you want to use the controller with a single

camera.

1. Touch “ ” on the screen.

2. Touch the screen of the camera you want to use.

This exits the Multi Camera Mode and displays the image of the camera you

selected above.

The controller will disconnect from the other camera (the one you did not select

above).

NOTE

• Turning off a camera while in the Multi Camera Mode will cause that camera to be

disconnected from the controller, and will automatically cause the controller to exit

the Multi Camera Mode. At this time the monitor screen will show the image of the

camera that is still turned on.

• Establishing a USB connection between a connected camera and a computer

(page 101) while in the Multi Camera Mode will automatically cause the controller

to exit the Multi Camera Mode. After that, the monitor screen will show the image of

the other camera.

93 Using Two Cameras at the Same Time (Multi

Camera Mode)

NOTE

• Simultaneous shooting with both cameras is not possible while either of the

cameras is recording a movie.

. Shooting with a Single Camera

You can use the operations below to shoot on either one of the cameras while

viewing images of both cameras on the Multi Image screen.

To shoot a snapshot

1. Press the Camera 1 or Camera 2 shutter button.

This shoots a snapshot on the camera whose shutter button you pressed.

To shoot a movie

1. Press the Camera 1 or Camera 2 [0] (Movie) button.

This starts movie recording on the camera whose button you pressed.

Press [0] (Movie) again to stop recording.

. Interval Shooting with Two Cameras

Use the procedure below to perform an Interval Shooting operation with two cameras.

1. Touch “ ”.

This will displays the Interval Shooting setting screen.

2. Configure Interval Shooting settings as desired, and then touch

“Start”.

This applies the settings to both cameras and starts simultaneous Interval

Shooting with them.

• See page 44 for information about Interval Shooting.

NOTE

• Interval Shooting is automatically cancelled if either camera is unable to shoot for

some reason.

• Depending on the type of memory cards you are using and shooting conditions,

there may be some lag between the shooting operations of the two cameras. In

order to enable simultaneous shooting with two cameras, use of memory cards of

the same type that have been formatted on the cameras is recommended.

94 Using Two Cameras at the Same Time (Multi

Camera Mode)

. Multi Image Screen Operations

• You cannot configure camera REC mode settings while the Multi Image screen is

displayed. To configure such settings, touch “ ” or “ ” to display the Single

Image screen of the camera whose REC mode settings you want to configure, and

then touch the REC Mode icon. For information about the REC mode, see page 41.

After you are finished configuring settings, touch “ ” to return to Multi Image

screen.

• You cannot change movie quality, or configure other REC menu settings while the

Multi Image screen is displayed. To configure such settings, touch “ ” or “ ” to

display the Single Image screen of the camera whose REC menu settings you

want to configure, and then touch “MENU”. For information about the REC menu,

see page 52. After you are finished configuring settings, touch “ ” to return to

Multi Image screen.

• You cannot perform zoom operations while the Multi Image screen is displayed. To

perform such operations, touch “ ” or “ ” to display the Single Image screen of

the camera whose image you want zoom, and then perform the zoom operation

you want. After you are finished, touch “ ” to return to Multi Image screen with

your zoom setting maintained.

95 Using Two Cameras at the Same Time (Multi

Camera Mode)

You can use the operations below to shoot with either one of the cameras while

viewing its image on the Single Image screen.

. To switch the Single Image screen between the two cameras

(Camera 1, Camera 2)

1. Touch “ ” or “ ”.

Each touch toggles between Camera 1 and Camera 2.

. To shoot a snapshot

1. Press the controller shutter button.

This records a snapshot on the currently displayed camera.

NOTE

• You can also record a snapshot on a particular camera by pressing the camera’s

shutter button.

. To shoot a movie

1. On the controller, press [0] (Movie).

This starts movie recording on the currently displayed camera.

Press [0] (Movie) again to stop recording.

NOTE

• You can also record a movie on a particul ] ar camera by pressing the camera’s [0

(Movie) button. Press [0] (Movie) again to stop recording.

Shooting with the Single Image Screen

Camera 1 or Camera 2 REC screen

Exits the Multi Camera Mode.

Switches to the Multi

Image screen.

Switches the Single

Image screen

between the two

cameras.

Touch to select a

recording mode

(pages 34, 41).

96 Using Two Cameras at the Same Time (Multi

Camera Mode)

. Single Image Screen Operations

• Menu screen, REC mode screen, and wireless mode settings you configure for

Camera 1 or Camera 2 on the Single Image screen are maintained when you

return to Multi Image screen and even when you exit the Multi Camera Mode.

• On the Single Image screen, the setting of Review (page 61) is always “Off”.

98 Using Two Cameras at the Same Time (Multi

Camera Mode)

. To playback movies shot with both cameras simultaneously

1. On the Camera 1 or Camera 2 screen, display the movie you want to

view.

While there is a movie displayed on the playback screen of both Camera 1 and

Camera 2, “ ” (Movie) is displayed in the center of the screen.

2. Touch “ ” (Movie).

This starts simultaneous playback of both movies.

NOTE

• You cannot playback a movie from a particular camera while the Multi Image

screen is displayed.

. Multi Image Screen Operations

• Pressing the controller shutter button or [0] (Movie) button while the cameras are

in the PLAY mode will cause both cameras to switch simultaneously to the REC

mode.

• Pressing the shutter button or [0] (Movie) button of one of the cameras while it is in

the PLAY mode will start an image recording operation on that camera. The

controller will switch to the Single Image screen showing the image of the camera

that is recording the image.

• To view snapshot information, first touch “ ” or “ ” to display the Single Image

screen of the camera for the snapshot, and then view its information. After you are

finished, touch “ ” to return to the Multi Image screen.

100 Printing

Printing

There are a variety of different ways to print images stored on a computer. This

section shows one standard printing example.

. Printing on a Windows Computer

1. Use the procedure under “Viewing and Storing Images on a Computer”

(page 102) to store the image you want to print, and then display the

image on your computer screen.

2. Click “Print” and then “Print”.

3. Configure the desired print settings and then click “Print”.

. Printing on a Macintosh

1. Use the procedure under “Connecting the Camera to Your Computer

and Saving Files” (page 105) to store the image you want to print, and

then display the image on your Macintosh screen.

2. Click “File” and then “Print”.

3. Configure print settings and then click “Print”.

This will print the selected image.

Professional Print Service

You can take a memory card that contains the images you want

to print to a professional print service and have them printed.

Printing on a Home Printer

You can use a printer equipped with a memory card slot

to print images directly from a memory card. For details,

see the user documentation that comes with your

printer.

Printing with a Computer

After transferring the images to your computer, use

commercially available software to print.

Printing with a Computer

101 Using the Camera with a Computer

Using the Camera with a Computer

You can perform the operations described below while the camera is connected to a

computer.

The procedures you need to perform are different for Windows and the Macintosh.

• The above recommended computer system environments do not guarantee proper

operation.

• The type of computer being used, certain settings, and other installed software

may interfere with proper operation.

Things you can do using a computer...

Save images to a

computer and

view them there

• Save images and view them manually

(USB connection) (pages 102, 105).

Play back and

edit movies

• You can play back movies (pages 104,

107).

• To edit movies, use commercially

available software as required.

• Windows users should refer to “Using the Camera with a Windows Computer”

on page 101.

• Macintosh users should refer to “Using the Camera with a Macintosh” on page

105.

Using the Camera with a Windows Computer

When you want to

do this:

Operating

System Version Required Software

Save images to a

computer and view

them there manually

Windows 10,

Windows 8.1,

Windows 7,

Windows Vista

Installation not required.

Play movies

Windows 10,

Windows 8.1,

Windows 7

Windows Media Player 12

Windows Vista

Software that can play movie files with

the file name extension MOV.

You may need to download the software

on the Web.

102 Using the Camera with a Computer

You can connect the camera to your computer in order to view and store images

(snapshot and movie files).

IMPORTANT!

• Never unplug the USB cable, or operate the camera while viewing or storing

images. Doing so can cause data to become corrupted.

NOTE

• You also can use your computer’s card slot (if it has one) or a commercially

available card reader to access image files directly from the camera’s memory

card. For details, see the user documentation that comes with your computer.

. To connect the camera to your computer and save files

1. On the camera, hold down [p]

(Power) for about two seconds

to turn off power. Next, use the

micro USB cable that comes

with the camera to connect it

to your computer’s USB port.

• For details about connecting to

the camera and precautions

when connecting, see page 24.

2. Press [p] (Power) to turn on the camera.

When you turn on the camera, check to make sure that the color of its operation

lamp changes from red to green or amber (page 24). Note that in this case the

monitor screen will remain blank.

• The first time you connect the camera to your computer with the USB cable, an

error message may appear on your computer. If this happens, disconnect and

then reconnect the USB cable.

Viewing and Storing Images on a Computer

Never use your computer to modify, delete, move, or rename any image files

that are in the camera’s built-in memory or on its memory card.

Doing so can cause problems with the camera’s image management data, which

will make it impossible to play back images on the camera and can drastically alter

remaining memory capacity. Whenever you want to modify, delete, move, or

rename an image, do so only on images that are stored on your computer.

USB

Micro USB cable

(included with camera)

[USB] port

104 Using the Camera with a Computer

. To view images you copied to your computer

1. Double-click the copied “DCIM” folder to open it.

2. Double-click the folder that contains the images you want to view.

3. Double-click the image file you want to view.

• For information about file names, see “Memory Folder Structure” on page 109.

• An image that was rotated on the camera will be displayed on your computer

screen in its original (unrotated) orientation.

• Viewing CS and interval shot images on a computer will individually display the

component images in the group. CS and interval shooting images cannot be

viewed as a group on a computer.

. Movie Playback Precautions

• To play back a movie, first save it to your computer and then double-click the movie

file. Proper movie playback may not be possible for data accessed over a network,

from a memory card, etc.

• Proper movie playback may not be possible on some computers. If you experience

problems, try the following.

– Quit any other applications you have running, and stop resident applications.

105 Using the Camera with a Computer

• The above recommended computer system environments do not guarantee proper

operation.

• Proper operation depends on the level of performance of the computer you are

using.

IMPORTANT!

• Never unplug the USB cable, or operate the camera while viewing or storing

images. Doing so can cause data to become corrupted.

• The camera does not support operation with Mac OS X 10.0 to 10.4. Operation is

supported with Mac OS 10.5 to 10.11 (using the OS standard USB driver) only.

NOTE

• You also can use your computer’s card slot (if it has one) or a commercially

available card reader to access image files directly from the camera’s memory

card. For details, see the user documentation that comes with your computer.

Using the Camera with a Macintosh

When you want to do this:

Operating

System Version

Required Software

Save images to your

Macintosh and view them

there manually

OS X Installation not required.

Save images to your

Macintosh automatically/

Manage images

OS X

Photos or iPhoto, which comes

bundled with some Macintosh

products.

Play movies OS X 10.5 or

higher

QuickTime Player

(installed on computer)

Connecting the Camera to Your Computer and Saving Files

Never use your computer to modify, delete, move, or rename any image files

that are in the camera’s built-in memory or on its memory card.

Doing so can cause problems with the camera’s image management data, which

will make it impossible to play back images on the camera and can drastically alter

remaining memory capacity. Whenever you want to modify, delete, move, or

rename an image, do so only on images that are stored on your computer.

107 Using the Camera with a Computer

. To view copied images

1. Double-click the camera’s drive icon.

2. Double-click the “DCIM” folder to open it.

3. Double-click the folder that contains the images you want to view.

4. Double-click the image file you want to view.

• For information about file names, see “Memory Folder Structure” on page 109.

• An image that was rotated on the camera will be displayed on your Macintosh

screen in its original (unrotated) orientation.

. Movie Playback Precautions

• To play back a movie, first save it to your computer and then double-click the movie

file. Proper movie playback may not be possible for data accessed over a network,

from a memory card, etc.

• Proper movie playback may not be possible on some Macintosh models. If you

experience problems, try the following.

– Shut down other applications that are running.

108 Using the Camera with a Computer

The camera creates a file each time you shoot a snapshot, record a movie, or

perform any other operation that stores data. Files are grouped by storing them in

folders. Each file and folder has its own unique name.

• For details about how folders are organized in memory, see “Memory Folder

Structure” (page 109).

• You can view folder and file names on your computer. For details about how file

names are displayed on the camera’s monitor screen, see page 10.

• The total number of folders and files allowed depends on the image size and

quality, and capacity of the memory card being used for storage.

Files and Folders

Name and Maximum Number Allowed Example

File

Each folder can contain up to 9999 files named

CIMG0001 through CIMG9999. The extension

on the file name depends on the file type.

26th file name:

Folders

Folders are named from 100CASIO to

999CASIO.

There can be up to 900 folders in memory.

100th folder name:


Extension

Serial number (4 digits)

100CASIO

Serial number (3 digits)

109 Using the Camera with a Computer

The camera stores images you shoot in accordance with the Design Rule for Camera

File System (DCF).

. About DCF

The following operations are supported for DCF-compliant images. Note, however,

that CASIO makes no performance guarantees concerning these operations.

• Transferring this camera’s DCF-compliant images to another manufacturer’s

camera and view them.

• Printing this camera’s DCF-compliant images on another manufacturer’s printer.

• Transferring another camera’s DCF-compliant images to this camera and view

them.

. Memory Folder Structure

DCIM Folder

Recording Folder

Image File

Movie File

Recording Folder

Recording information

*Used when creating a Highlight Photo or Highlight Movie.

. Supported Image Files

• Image files shot with this camera

• DCF-compliant image files

This camera may not be able to display an image, even if it is DCF-compliant. When

displaying an image recorded on another camera, it may take a long time for the

image to appear on this camera’s monitor screen.

Memory Card Data

DCIM

EXILIM

100CASIO

HL_DATA *


CIMG0002.MOV

101CASIO

102CASIO

MD2016

MD01010E.CMI

MD01010T.CMI

MD2017

110 Using the Camera with a Computer

. Built-in Memory and Memory Card Data Handling Precautions

• Whenever copying memory contents to your computer, you should copy the DCIM

folder and all of its contents. A good way to keep track of multiple DCIM folders is

to change their names to dates or something similar after you copy them to your

computer. If you later decided to return a DCIM folder to the camera, however, be

sure to change its name back to DCIM. The camera is designed to recognize only a

root file with the name DCIM. Note the camera also will not be able to recognize the

folders inside the DCIM folder unless they have the names they originally had

when you copied them from the camera to your computer.

• Folders and files must be stored in accordance with the “Memory Folder Structure”

shown on page 109 in order for the camera to be able to recognize them correctly.

111 Other Settings (Set Up)

Other Settings (Set Up)

This section explains menu items that you can use to configure settings and perform

other operations in both the REC mode and PLAY mode.

Procedure

MENU * “¥ Setup” Tab * Screen

You can use the following procedure to change the brightness of the monitor screen.

Procedure

MENU * “¥ Setup” Tab * Info

Selecting “On” displays setup status and other information.

For information about menu operations, see page 52.

Adjusting Monitor Screen Brightness (Screen)

+2 Brightness that is greater than +1, which makes the screen easier to view.

This setting consumes more power.

+1 Bright setting for outdoor use, etc. Brightness that is greater than 0.

0 Normal monitor screen brightness for indoor use, etc.

–1 Screen brightness for viewing in a dark environment without disturbing

others around you.

Selecting Display Information (Info)

112 Other Settings (Set Up)

Procedure

MENU * “¥ Setup” Tab * Rotation Lock

You can use this setting to fix the orientation of the camera or controller screen

image, or allow the orientation to be detected and automatically rotated as required.

NOTE

• Certain playback environment may cause images to be displayed using the wrong

orientation.

Procedure

MENU * “¥ Setup” Tab * Camera Sound

You can adjust the volume of the sound emitted when the camera is turned on, when

an image is shot, when an error occurs, etc.

• Regardless of this setting, no recording sound is emitted during an Interval

Shooting operation.

Locking the Camera or Controller Screen Orientation

(Rotation Lock)

Camera

Off

The camera detects its orientation when you are

shooting, and stores orientation information along

with the image data. During playback of an image,

it is displayed in accordance with the orientation

information.

On The camera does not detect its orientation, and

images are always stored in landscape orientation.

Controller

Off Display image is rotated according to the controller

orientation.

Display image orientation is fixed at where it was

when “On” is selected for the controller’s Rotation

Lock setting.

Configuring Camera Sound Settings (Camera Sound)

High volume

Low volume

113 Other Settings (Set Up)

Procedure

MENU * “ Vibration¥ Setup” Tab *

While “On” is selected for this function, the controller will vibrate whenever any one of

the events described below occurs.

• When a “Type 1” review image is displayed on the controller immediately after

shooting

• When communication between the camera and controller is lost

• When an error occurs

• While focus is locked

Procedure

MENU * “¥ Setup” Tab * Adjust

1. Touch the value you want to change (year,

month, day, hour, minute).

2. Touch “ ” or “ ” to change the currently

selected value.

• You can specify a date from 2001 to 2049.

• To switch between 12-hour and 24-hour format,

touch the 12/24 hour switch icon.

• Touching and holding “ ” or “ ” scrolls at high

speed.

3. Touch “OK”.

NOTE

• While the camera is connected to a smartphone with the EXILIM Connect app, you

can execute auto date and time adjustment. The camera’s time zone will be

changed automatically in accordance with the smartphone’s time zone. For details,

see the EXILIM Connect User’s Guide (page 74).

Using the Vibration Function (Vibration)

Setting the Camera’s Clock (Adjust)

12/24 hour switch icon

114 Other Settings (Set Up)

Procedure

MENU * “¥ Setup” Tab * Date Style

You can select from among three different styles for the date.

Example: July 10, 2017

Procedure

MENU * “¥ Setup” Tab * Language

. Specify the display language you want.

1. Flick upwards and downwards until you find the

language you want, and then touch to select it.

• Camera models sold in certain geographic areas may not support display language

selection.

Procedure

MENU * “¥ Setup” Tab * Sleep

Use this function to specify how much time should be allowed to laps until the

controller display goes blank and the controller enters the sleep state. You can

specify either 30 seconds (30 sec), 1 minute (1 min) or 5 minutes (5 min).

Specifying the Date Style (Date Style)

YY/MM/DD 17/7/10

DD/MM/YY 10/7/17

MM/DD/YY 7/10/17

Specifying the Display Language (Language)

Specifying the Controller Sleep State Trigger Time (Sleep)
