Strona 1/4
Designed by BDI Studio.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Sigma & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2019, BDI
Made in Turkey. 02.18.2019
C6 File Bar Clip x 8
C7 Swivel Locking Casters
x 5
C4 Small File Bar x 4
C5 Large File Bar x 2
Product Registration
Registering your BDI product allows us to provide you with important
product updates, service information and helpful advice. Register today,
and you’ll be entered to win a free gift from BDI: bdiusa.com/register
Placement and Maintenance
Sigma™ Office furniture is designed for indoor use on level floors. Clean
glass with glass cleaner, and other surfaces with a damp cloth.
Your Sigma ™ Office furniture is engineered for easy assembly.
Carefully follow this procedure to prevent any damage.
Do not use power tools for assembly of this product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware
pieces, please contact BDI Customer Service at customerservice@
bdiusa.com. For all other concerns, please contact your BDI retailer.
bdiusa.com
customerservice@bdiusa.com
SIGMATM 6916
LATERAL FILE CABINET
H1 Phillips M4
Screw x 20
Tool Required:
Phillips Screwdriver
C1 Glass Top x 1
A1 Cabinet x 1
bdiusa.com
customerservice@bdiusa.com
SIGMA 6916
LATERAL FILE CABINET
2
Step 2 - Before installing the glass, carefully lay the cabinet on its back. Attach to casters C7 Cabinet A1
using Screws H1 and tighten with a Phillips Screw Driver.
H1 x 20
C7 x 5
2 Person skTa
Step 3 - With help from another person, stand the cabinet onto its wheels.
Step 4 - Position the glass panel on top of the cabinet and align all edges.
The glass should be inset 1/16” (1.5mm).
1.5 mm
bdiusa.com
customerservice@bdiusa.com
SIGMA 6916
LATERAL FILE CABINET
3
Step 5 - Casters - The casters can be locked by pressing the lever downward and released by pressing the
lever upward.
Step 6 - File Bar Installation (Option A)
For files facing forward, attach File Bar Clip C6 Small File Bar to both ends of C4 as shown.
For letter files, use the outer notches on the front and back of the drawer. For legal files, use the inner notches.
C6 x 4
C4 x 2
Use this notch
for legal files
