Strona 1/25
................ page 13
................ page 12
................ page 11
................ page 10
................ page 14
a. Unscrew the six screws which fi x the glass panel
b. Reassemble the glass panel. Fasten the six closing screws
................ page 14
a. Unscrew the two screws which fi x the side handle
b. Reassemble the side handles by fastening the proper screws
................ page 15
a. Remove the glass panel
b. Remove the side handle above power supply terminal blocks
c. Lift the plexiglass panel which protects power supply terminal blocks
d. Remove the two parts of the fuse to be replaced
e. Eliminate all possible metallic remainders of the broken fuse and install the new one
f. Mount power supply terminal blocks protecting panel
g. Mount the side handle back
h. Reassemble the glass panel
................ page 16
a. Remove the glass panel
b. Remove the side handle above power supply terminal blocks
c. Lift the plexiglass panel which protects power supply terminal blocks
d. Find the 4 blade mini-fuses
e. Mount power supply terminal blocks protecting panel
f. Mount the side handle back
g. Reassemble the glass panel
................. pag. 17
a. Remove the glass panel
b. Set BIAS switch on “L or on “H”
c. Reassemble the glass panel
................ page 18
a. Remove the glass panel
b. Remove the bypass module
c. Select the fi lter and the frequency you like
d. Install the crossover module
e. Reassemble the glass panel
................ page 19
a. Accessories supplied with HV venti
b. How to take the amplifi er out of its inner carton
c. If you like to change DUAL POWER confi guration...
d. If you like to change DUAL BIAS confi guration...
e. If you like to install the electronic CROSSOVER...
f. NON-PROJECTING or SEMI-PROJECTING installation (adhesive template)
g. Remove the ampli er fi xing plate
h. Secure the fi xing plate
i. Secure the ampli er to the fi xing plate
j. Connect signal cables...
k. Connect power supply cables...
l. Amplifi er calibration...
m. Mount the grilles which cover connections onto side handles
n. Reassemble both side handles...
a. Fans protecting fi lters cleaning
b. Cooling ducts cleaning
................ page 24
................ page 9
................ page 3
1 • Project purpose
2 • Project philosophy
3 • Electronics
4 • Chassis and thermal project
5 • Installation method and maintenance
................ page 2
Safety precautions
Functioning precautions
Maintenance and reliability precautions
MAINTENANCE
12 OWNER’S MANUAL
INSTALLATION
11 OWNER’S MANUAL
CROSSOVER INSTALLATION
10 OWNER’S MANUAL
DUAL BIAS CONFIGURATION
9 OWNER’S MANUAL
DUAL POWER CONFIGURATION
8 OWNER’S MANUAL
MAIN FUSE REPLACEMENT
7 OWNER’S MANUAL
SIDE HANDLES
6 OWNER’S MANUAL
GLASS PANEL REMOVAL
5 OWNER’S MANUAL
CONTROL FUNCTIONS AND PROTECTION
4 OWNER’S MANUAL
CONTROLS PANEL
3 OWNER’S MANUAL
POWER SUPPLY - SWITCHING ON PANEL
2 OWNER’S MANUAL
INPUTS - OUTPUTS PANEL
1 OWNER’S MANUAL
TECHNICAL AND ELECTRICAL FEATURES
1 TECHNICAL DATA
DESCRIPTION
2 INTRODUCTION
GENERAL RECOMMENDATIONS
1 INTRODUCTION
CONTENTS
- 1 -
i
Safety precautions
The vehicle electric system must have 12VDC voltage with negative to ground. Make sure your car has it in order to
avoid any damages to your amplifier and to the car itself.
Suitably fix the amplifier paying utmost attention if you install it into the driver’s compartment. Use extra fixing systems
if you install it inside the bonnet. If the amplifier detaches itself while you are driving, it can severely damage people and
other vehicles.
Power supply cable must have mechanically resistant and self-extinguishing insulation. Its section has to comply with
what is indicated in this manual. When placing it, avoid to press it against cutting parts or close to mechanical moving
objects. Make sure it is suitably fixed all along its length. Block positive and negative cables just close to the amplifier
respective power supply terminal blocks through a clamping screw.
Put a fuse holder close to the battery positive terminal; connect one end of the power supply cable to it after
connecting its other end to the amplifier. The fuse value must be 50% higher than the amplifier built-in one. In case
the cable supplies several amplifiers, the fuse value will have to be 50% higher than the sum of the values of all other
fuses in the system.
For safer driving, we recommend to adjust volume not to drown external traffic sounds.
WARNING. When the amplifier works in particularly hard conditions, it can reach 90°C (194°F). Make sure its
temperature is safe before touching it.
Functioning precautions
Install the amplifier in locations where temperature is between 0°C (32°F) and 55°C (131°F).
There must be suitable air circulation where you install the amplifier; this area must not be affected by humidity, rain,
external deposits or parts coming from the vehicle mechanical devices. Let the amplifier glass upper part (i.e. the part
where air goes in and out) be at least 10 cm (4”) far from possible walls.
When installing speakers and the cables that connect them, make sure that non-insulated parts never touch the car
cutting parts. If they do, the amplifier protection intervenes.
Listening level calibration is made by adjusting the source volume up to 3/4 of its maximum level; then, adjust the
amplifier levels until you can hear distortion and you can see PEAK indicators are occasionally on.
Avoid to start the car engine with the amplifier on. If the battery isn’t sufficiently charged, in case you start the car with
the audio system on, the amplifier could go in the protection mode.
In this case isn’t sufficient to shut off the audio system and turn it on after some seconds.
Maintenance and reliability precautions
Periodically clean the amplifier avoiding to use aggressive solvents that might damage it. Dampen a piece of cloth with
water and soap, wring it and clean the amplifier with it. Then, clean the amplifier by using a piece of cloth dampened with
water only; eventually clean it with a dry piece of cloth.
Remove dust and solid deposits from the five upper grilles through which air goes in and out. This must be periodically
done by removing the magnetic fixing grilles and by cleaning the filter you can find underneath them as indicated in
this manual. Avoid to use compressed air on the grilles without removing them, since it would push solid parts into the
amplifier. If necessary, please contact a specialised service centre for internal cleaning. Air ducts obstruction makes the
amplifier go in safety.
- 2 -
GENERAL RECOMMENDATIONS
INTRODUCTION
1
