1
MBK302S Installation Manual
COMPONENTS
MBK310 FX Series y frame
MBK318 Side + back board set for FX1.18
MBK315 Side board set for FX3.15
MBK320 Connection board set 20°-60°
1x
2x
2x
2x
FX1.18 Loudspeaker cabinet
(not included with MBK302S)
FX3.15 Loudspeaker cabinet
(not included with MBK302S)
1x
1x
Bow shackle 1.5ton
(not included with MBK302S, to be sourced locally because
of local legislation)
2x
Steel safety wire Ø 8 mm - 3250 mm
(not included with MBK302S, to be sourced locally because
of local legislation)
1x
Steel safety wire Ø 8 mm - 3150 mm
(not included with MBK302S, to be sourced locally because
of local legislation)
1x
ISO 4762 - M10 x 20 mm + DIN 7980 - M10 14x +
1x
MBK302S Installation Manual
2
IMPORTANT SAFETY INSTRUCTIONS
READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY
Read these instructions and keep them. Never throw them away
Heed all safety warnings
Follow all instructions
Personnel qualication
Installation and set-up should only be carried out by qualied personnel that are familiar
with rigging techniques and safety recommendations that are outlined in this manual.
System parts and rigging instruction
All system components must be inspected before use, in order to detect any possible
defects. Any part showing any sign of defect must immediately be put aside and with-
drawn from use to be inspected by qualied service personnel.
Additional rigging equipment
Only use rigging and mounting accessories which are specied by the manufacturer of
this mounting bracket. It is the users responsibility to ensure that the working load limit
of additional accessories is greater than the total weight of the loudspeaker assembly.
Suspension points
It is the users responsibility to ensure that the suspension points can support the total
weight of the loudspeaker assembly.
Local regulations
Some countries require higher safety factors and rigging approvals. Always follow the
local regulations, even if otherwise specied in this instruction manual. It is the users
responsibility to guarantee that all mountings and connections are made in accordance
with all applicable local regulations.
Flying a loudspeaker assembly
Always ensure that nobody is standing underneath the loudspeaker assembly when it is
being raised. Never leave the system unattended during the installation process.
Dynamic load
When a loudspeaker assembly is deployed in an open air environment, wind eects
should be taken into account. Wind can produce dynamic stress to the bracket compo-
nents and suspension points.
Periodic inspection
If all the system components are inspected and approved before use and installed as
described in this manual, they will remain fully operational over the systems lifetime.
However, an annual system inspection of the system and especially the suspension
points shall be performed by qualied personnel to check for any defects caused by
external inuences.
CE DECLARATION OF CONFORMITY
This product conforms to all the essential requirements and
further relevant specications described in following directives:
2006/42/EC Machinery directive
3
MBK302S Installation Manual
PROCEDURE
1Remove the U-proles from FX1.18 and FX3.15 cabinets at the sides and back. Keep the bolts nearby because
you will need them in step 2.
2Mount the FX1.18 side and back plates to the FX1.18 cabinet and the FX3.15 side plates to the FX3.15 cabinet.
You can use the bolts that were removed in step 1.
